Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
147cm - 151cm
SM
148cm - 156cm
MD
153cm - 167cm
LG
164cm - 175cm
XL
185cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Fitness, 6061 Aluminum, 700C Wheels, Step-Thru Design, Disc Brakes, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Disc Mount, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY510
Shift Levers
Shimano EF41 Shifter/Brake Lever Combo, 3x7-Speed
Cassette
KMC Z50
Crank
Forged aluminum, 48/38/28T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Marin Fitness 700Cx35
Brakes
Brakes
Tektro Mechanical Disc Brake
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy Threadless
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Commute
Headset
FSA, Threadless
Seat
Saddle
Marin Women's Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm | 1.46 mm | 1.48 mm | 1.49 mm |
| Bottom Bracket Height | 300 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 586 mm | 591 mm | 606 mm | 621 mm | 636 mm |
| Rake | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 61 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 545 mm | 558.89 mm | 577.97 mm | 597.04 mm | 616.11 mm |
| Reach | 375 mm | 385.74 mm | 395.09 mm | 404.44 mm | 412.94 mm |
| Top Tube Length | 536 mm | 551 mm | 566 mm | 581 mm | 601 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 350 mm | 381 mm | 431.8 mm | 482.6 mm | 520.7 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1010 mm | 1015 mm | 1030 mm | 1046 mm | 1060 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 590 mm | 614 mm | 657 mm | 701 mm | 735 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 148 cm | 153 cm | 164 cm | 185 cm |
| Rider Max Height | 151 cm | 156 cm | 167 cm | 175 cm | 190 cm |
Model Overview
Terra Linda 1 belongs to the Marin Terra model. Marin released 17 bikes variations of this model so far. Take a sneak peek at all Marin Terra bikes models from 2020, by clicking here.
Model range prices
Marin Terra Linda 1 2020 is the most economical model, with a starting price of 429$. Marin Terra Linda 3 2020 on the other hand costs 879$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Marin released this model in 2020, its price was 429$. In conclusion, this bike price is 52.91% smaller than the price of the average Fitness bike.
Overview of components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
As for the wheels, Marin Terra Linda 1 2020, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Terra Linda 1 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 147 cm – 190 cm (4.82 ft – 6.23 ft). In short, you can easily find one that suits you.
