Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCM HLO
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 159cm
SM
156cm - 167cm
MD
164cm - 174cm
LG
171cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, Women's Specific Frame, 27.5" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing Routing
Suspension Fork
SR Suntour XCM HLO, 120mm Travel, Hydraulic Lockout, 46mm Offset
Drivetrain
Rear Derailleur
Shimano Altus, 8-Speed
Front Derailleur
Altus Double
Shift Levers
Shimano Altus SL-M315, 8-Speed
Cassette
SunRace 8-Speed, 11-34T
Crank
Alloy Crank, Steel Chainrings, 36/22T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc, 32H
Rear Hub
Forged Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 25mm Inner, Pinned Joint, Disc Specific
Tires
MTB, 27.5x2.25"
Brakes
Brakes
hydraulicDisc
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin Alloy, 31.8mm Clamp, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 740mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 688 mm | 705 mm | 717 mm | 739 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 107 mm | 107 mm | 107 mm | 107 mm |
| Stack | 592.7 mm | 597.3 mm | 602 mm | 606.6 mm |
| Reach | 418 mm | 433 mm | 443 mm | 463 mm |
| Top Tube Length | 578 mm | 594.3 mm | 605.6 mm | 626.8 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 481 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1107 mm | 1123 mm | 1135 mm | 1158 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 598 mm | 619 mm | 658 mm | 704 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 156 cm | 164 cm | 171 cm |
| Rider Max Height | 159 cm | 167 cm | 174 cm | 180 cm |
About this model
Wildcat Trail 3 is part of the Marin Wildcat model. Marin launched 31 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Marin Wildcat Trail 1 2022 is the most economical model, with a starting price of 599$. Marin Wildcat Trail 3 2022 on the other hand costs 819$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2022, its price was 819$. Doing a quick comparison, we notice that Wildcat Trail 3 price is 237.24% smaller than the average cost of a Trail bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Suntour XCM HLO is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Wildcat Trail 3 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Wildcat Trail 3 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 147 cm – 180 cm (4.82 ft – 5.91 ft). In conclusion, you won’t have a problem finding one that suits you.
