Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCR
-
Groupset Deore, microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 159cm
SM
156cm - 167cm
MD
164cm - 174cm
LG
171cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, Women's Specific Frame, 27.5" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing Routing
Suspension Fork
SR Suntour XCR LOR-DS, Thru-Axle, 120mm Travel, Hydraulic Lockout, Damping Adjustment, 44mm Offset
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS
Front Derailleur
-
Shift Levers
MicroSHIFT 1x11-Speed
Cassette
SunRace 11-Speed, 11-46T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Nylon Platform
Wheels
Front Hub
Formula, 100x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H
Rear Hub
Forged Alloy, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Trailboss Comp, 27.5/29x2.25, Wire Bead
Brakes
Brakes
Shimano BR-MT201 Hydraulic Disc 180mm Rotor
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Marin Alloy, 31.8 Bar Bore, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 696 mm | 713 mm | 725 mm | 746 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 592.7 mm | 597.3 mm | 602 mm | 606.6 mm |
| Reach | 418 mm | 433 mm | 443 mm | 463 mm |
| Top Tube Length | 583 mm | 599 mm | 610.5 mm | 631.8 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 481 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1114 mm | 1131 mm | 1143 mm | 1165 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 619 mm | 656 mm | 701 mm | 741 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 156 cm | 164 cm | 171 cm |
| Rider Max Height | 159 cm | 167 cm | 174 cm | 177 cm |
About this model
Wildcat Trail 5 is part of the Marin Wildcat model. Marin launched 31 bikes of this model so far. Take a sneak peek at all Marin Wildcat bikes models from 2020, by clicking here.
Model range prices
Marin Wildcat Trail 1 2020 is the cheapest bike model and costs 429$. Marin Wildcat Trail 5 2020 is the most expensive one and costs 899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2020 and its price was 899$. In conclusion, this bike price is 207.23% lower than the price of the average Trail bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Wildcat Trail 5 components
Fork
Marin Wildcat Trail 5 2020 bike is equipped with the SunTour XCR fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Wildcat Trail 5 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Wildcat Trail 5 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 147 cm – 177 cm (4.82 ft – 5.81 ft). In conclusion, finding one for you shouldn’t be a problem.
