Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT Advent X, FSA -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Brunello gravel | Smooth welded double-butted aluminum | 1.125 - 1.5" integrated head tube | BB86 bottom bracket | Flat-mount disc brake | Replaceable derailleur hanger | Internal dropper post compatible | 12 x 142mm thru-axle
Suspension Fork
Brunello gravel | MC-9 carbon construction | Carbon 1.125 - 1.5" tapered steer tube | Flat-mount disc | Fender mounts | 12 x 100mm thru-axle
Drivetrain
Rear Derailleur
microSHIFT RD-M6205AM with clutch 10s
Front Derailleur
--
Shift Levers
microSHIFT ADVENT X
Cassette
Sunrace CS-H103A | 10-spd | 11-42T
Crank
FSA Pro Modular AGX+ | 40T chainring | 47cm: 165mm, 51cm : 170mm, 54-56cm : 172.5mm, 58-60cm : 175mm
Bottom Bracket
FSA BB86 EVO
Chain
KMC X10
Pedals
--
Wheels
Front Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rear Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rims
Brev M. 700c Performance Gravel Disc | Depth: 23mm, Width (internal): 21mm | 28H | Double wall | Tubeless compatible
Tires
Hutchinson Overide | 700x38c | Bi-compound | Folding
Brakes
Brakes
Rever MCX2 disc | Flat mount | Dual piston | 6-bolt rotors, 160mm
Brake Levers
microSHIFT ADVENT X
Cockpit
Stem
Brev M. Gravel Race | 3D forged alloy | -7° drop | 47cm: 90mm, 51-54cm: 100mm, 56-58cm: 110mm, 61cm: 120mm
Handlebar
Brev M. alloy all-road bend | ? 31.8mm | 120mm drop | 75mm reach | 47cm: 40cm, 51-56cm: 42cm, 58-60cm: 44cm
Headset
FSA 42E 1.5" tapered
Seat
Saddle
Masi Gravel Performance
Seatpost
Brev M. Carbon | ? 27.2mm x 300mm | 10mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.45 mm | 1.47 mm | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 597 mm | 605 mm | 612 mm | 619 mm | 626 mm | 635 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 67 mm | 66 mm | 65 mm | 66 mm | 66 mm |
| Stack | 557 mm | 565 mm | 586 mm | 600 mm | 616 mm | 635 mm |
| Reach | 394 mm | 400 mm | 405 mm | 407 mm | 409 mm | 412 mm |
| Top Tube Length | 547 mm | 555 mm | 570 mm | 580 mm | 587 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.7 ° | 73.7 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71.8 ° | 71.8 ° | 72.2 ° | 72.2 ° | 72.2 ° | 72.2 ° |
| Head Tube Length | 114.5 mm | 123 mm | 144 mm | 158.5 mm | 175 mm | 195.5 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1017 mm | 1025 mm | 1032 mm | 1039 mm | 1046 mm | 1055 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 739 mm | 768 mm | 794 mm | 813 mm | 832 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Brunello ADX is part of the Masi Brunello model. There are 7 bikes that carry this model name. You can easily view all of the Masi Brunello bikes models from 2022, here.
Model range prices
Masi Brunello FB Nove 2022 is the most affordable bike of this model and has a price of 1149$. On the other hand, Masi Brunello ADX 2022, is the most expensive and costs 1699$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1699$. Doing a quick comparison, we notice that Brunello ADX price is 44.91% lower than the average cost of a Gravel bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
Brunello ADX has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Brunello ADX 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
