Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT Advent X, FSA -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Brunello gravel | Smooth welded double-butted aluminum | 1.125 - 1.5" integrated head tube | BB86 bottom bracket | Flat-mount disc brake | Replaceable derailleur hanger | Internal dropper post compatible | 12 x 142mm thru-axle
Suspension Fork
Brunello gravel | MC-9 carbon construction | Carbon 1.125 - 1.5" tapered steer tube | Flat-mount disc | Fender mounts | 12 x 100mm thru-axle
Drivetrain
Rear Derailleur
microSHIFT RD-M6205AM with clutch 10s
Front Derailleur
--
Shift Levers
microSHIFT ADVENT X
Cassette
Sunrace CS-H103A | 10-spd | 11-42T
Crank
FSA Pro Modular AGX+ | 40T chainring | 47cm: 165mm, 51cm : 170mm, 54-56cm : 172.5mm, 58-60cm : 175mm
Bottom Bracket
FSA BB86 EVO
Chain
KMC X10
Pedals
--
Wheels
Front Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rear Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rims
Brev M. 700c Performance Gravel Disc | Depth: 23mm, Width (internal): 21mm | 28H | Double wall | Tubeless compatible
Tires
Hutchinson Overide | 700x38c | Bi-compound | Folding
Brakes
Brakes
Rever MCX2 disc | Flat mount | Dual piston | 6-bolt rotors, 160mm
Brake Levers
microSHIFT ADVENT X
Cockpit
Stem
Brev M. Gravel Race | 3D forged alloy | -7° drop | 47cm: 90mm, 51-54cm: 100mm, 56-58cm: 110mm, 61cm: 120mm
Handlebar
Brev M. alloy all-road bend | ? 31.8mm | 120mm drop | 75mm reach | 47cm: 40cm, 51-56cm: 42cm, 58-60cm: 44cm
Headset
FSA 42E 1.5" tapered
Seat
Saddle
Masi Gravel Performance
Seatpost
Brev M. Carbon | ? 27.2mm x 300mm | 10mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.45 mm | 1.47 mm | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 597 mm | 605 mm | 612 mm | 619 mm | 626 mm | 635 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 67 mm | 66 mm | 65 mm | 66 mm | 66 mm |
| Stack | 557 mm | 565 mm | 586 mm | 600 mm | 616 mm | 635 mm |
| Reach | 394 mm | 400 mm | 405 mm | 407 mm | 409 mm | 412 mm |
| Top Tube Length | 547 mm | 555 mm | 570 mm | 580 mm | 587 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.7 ° | 73.7 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71.8 ° | 71.8 ° | 72.2 ° | 72.2 ° | 72.2 ° | 72.2 ° |
| Head Tube Length | 114.5 mm | 123 mm | 144 mm | 158.5 mm | 175 mm | 195.5 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1017 mm | 1025 mm | 1032 mm | 1039 mm | 1046 mm | 1055 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 739 mm | 768 mm | 794 mm | 813 mm | 832 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Brunello ADX is part of the Masi Brunello model. There are 7 bikes that carry this model name. Take a sneak peek at all Masi Brunello bikes models from 2023, by clicking here.
Model range prices
Masi Brunello R10 2023 is the cheapest bike model and costs 1549$. Masi Brunello ADX 2023 is the most expensive one and costs 1699$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Masi released this model in 2023, its price was 1699$. If we compare this with the average Gravel bike cost we notice that the price is 44.91% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Brunello ADX components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Brunello ADX bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Brunello ADX has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
