Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tig Welded Double Butted Chromoly Tubing, Flatmount Disc Mount
Suspension Fork
Dirt-Tuned MC7 Carbon w/Alloy Steerer, Flatmount Disc Mount, 1 1/8"
Drivetrain
Rear Derailleur
Shimano 105 R5800
Front Derailleur
Shimano 105 R5800
Shift Levers
Shimano 105 R5800
Cassette
Shimano CS5800 11-32t 11-spd
Crank
Praxis Works Alba M24 48/32t
Bottom Bracket
Praxis Works M24, English 68mm
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Brev M. 23mm internal Tubeless Compatible, Double Wall
Tires
Kenda Flintridge 700x35mm, 30tpi
Brakes
Brakes
Promax MS3.3 Mechanical Disc, 160mm Rotor F/R
Brake Levers
Shimano 105 R5800
Cockpit
Stem
Brev. M 3D Forged Alloy, 31.8mm
Handlebar
Brev. M Compact Adventure Bend Alloy, 12 Degree Flair, 31.8mm
Headset
1 1/8" FSA Orbit X Sealed
Seat
Saddle
Masi Corsa Comp
Seatpost
Brev. M 3D Forged Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 51cm | 53cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.45 mm | 1.52 mm | 1.49 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 281 mm | 281 mm |
| Front Center | 576 mm | 582 mm | 585 mm | 594 mm | 615 mm | 625 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 67 mm | 62 mm | 67 mm | 65 mm | 66 mm |
| Stack | 524 mm | 535 mm | 551 mm | 582 mm | 595 mm | 625 mm |
| Reach | 377 mm | 379 mm | 380 mm | 384 mm | 398 mm | 400 mm |
| Top Tube Length | 525 mm | 535 mm | 540 mm | 560 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 535 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 81 mm | 98 mm | 113 mm | 143 mm | 161 mm | 185 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1003 mm | 1009 mm | 1012 mm | 1021 mm | 1043 mm | 1053 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 765 mm | 782 mm | 802 mm | 828 mm | 845 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
CXGR Expert is a Masi Cxgr model. Masi released 9 bikes variations of this model so far. Take a sneak peek at all Masi Cxgr bikes models from 2018, by clicking here.
Model range prices
Masi CXGR 2018 is the most economical model, with a starting price of 929$. Masi CXGR Expert 2018 on the other hand costs 1529$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Masi CXGR Expert price was 1529$. If we compare this with the average Gravel bike cost we notice that the price is 61.02% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The CXGR Expert 2018 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
