Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tig Welded Double Butted Columbus CRMOR Chromoly Tubing, Flatmount Disc Mount, 1 1/8"-1.5" Tapered H/T, 12mm F/R Thru-Axle
Suspension Fork
Dirt-Tuned MC7 Carbon w/Carbon Tapered 1 1/8"-1.5" Steerer, Flatmount Disc, 12mm Thru-Axle, Rack & Fender Mounts
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7000
Cassette
Shimano HG-700 11-34T 11-spd
Crank
Praxis Works Alba M30 48/32t
Bottom Bracket
Praxis Works M30 by Enduro, English 68mm
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Brev M. 23mm internal Tubeless Ready, Double Wall, 28h.
Tires
Kenda Flintridge 700x40mm, 60tpi Folding Bead
Brakes
Brakes
TRP Spyre-C Flat Mount Dual Pistion Mechanical Disc, 160mm Rotor F/R
Brake Levers
Shimano 105 R7000
Cockpit
Stem
Brev. M 3D Forged Alloy, 31.8mm
Handlebar
Brev. M Compact Adventure Bend Alloy, 12 Degree Flair, 31.8mm
Headset
Token 1 1/8"-1.5" Sealed Bearing
Seat
Saddle
Masi Corsa Comp
Seatpost
KS E-TEN 272 Remote, 27.2mm 65mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 51cm | 53cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.45 mm | 1.51 mm | 1.49 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 281 mm | 281 mm |
| Front Center | 581 mm | 582 mm | 584 mm | 600 mm | 619 mm | 629 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 62 mm | 68 mm | 65 mm | 60 mm | 61 mm | 62 mm |
| Stack | 520 mm | 536 mm | 552 mm | 580 mm | 595 mm | 623 mm |
| Reach | 378 mm | 380 mm | 381 mm | 383 mm | 398 mm | 400 mm |
| Top Tube Length | 525 mm | 535 mm | 540 mm | 560 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 535 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm | 160 mm | 170 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1008 mm | 1009 mm | 1011 mm | 1027 mm | 1047 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 765 mm | 782 mm | 802 mm | 828 mm | 845 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
CXGR Supremo belongs to the Masi Cxgr model. Masi launched 9 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Masi CXGR 2019 is the cheapest bike model and costs 979$. Masi CXGR Supremo 2019 is the most expensive one and costs 1949$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 1949$. Comparing this to the average Gravel bike price, we see that the price is 26.32% lower.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Masi CXGR Supremo 2019, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The CXGR Supremo has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Dropper post
Masi CXGR Supremo includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
