Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tig Welded Double Butted Columbus CRMOR Chromoly Tubing, Flatmount Disc Mount, 1 1/8"-1.5" Tapered H/T, 12mm F/R Thru-Axle
Suspension Fork
Dirt-Tuned MC7 Carbon w/Carbon Tapered 1 1/8"-1.5" Steerer, Flatmount Disc, 12mm Thru-Axle, Rack & Fender Mounts
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7000
Cassette
Shimano HG-700 11-34T 11-spd
Crank
Praxis Works Alba M30 48/32t
Bottom Bracket
Praxis Works M30 by Enduro, English 68mm
Chain
KMC X11
Pedals
N/A
Wheels
Front Hub
Alloy Disc Sealed Bearing, 12mm Thru-Axle, 28h
Rear Hub
Alloy Disc Sealed Bearing, 12mm Thru-Axle, 28h
Rims
Brev M. 23mm internal Tubeless Ready, Double Wall, 28h.
Tires
Kenda Flintridge 700x40mm, 60tpi Folding Bead
Brakes
Brakes
TRP Spyre-C Flat Mount Dual Pistion Mechanical Disc, 160mm Rotor F/R
Brake Levers
Shimano 105 R7000
Cockpit
Stem
Brev. M 3D Forged Alloy, 31.8mm
Handlebar
Brev. M Compact Adventure Bend Alloy, 12 Degree Flair, 31.8mm
Headset
Token 1 1/8"-1.5" Sealed Bearing
Seat
Saddle
Masi Corsa Comp
Seatpost
KS E-TEN 272 Remote, 27.2mm 65mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 51cm | 53cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.45 mm | 1.51 mm | 1.49 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 281 mm | 281 mm |
| Front Center | 581 mm | 582 mm | 584 mm | 600 mm | 619 mm | 629 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 62 mm | 68 mm | 65 mm | 60 mm | 61 mm | 62 mm |
| Stack | 520 mm | 536 mm | 552 mm | 580 mm | 595 mm | 623 mm |
| Reach | 378 mm | 380 mm | 381 mm | 383 mm | 398 mm | 400 mm |
| Top Tube Length | 525 mm | 535 mm | 540 mm | 560 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 535 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm | 160 mm | 170 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1008 mm | 1009 mm | 1011 mm | 1027 mm | 1047 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 765 mm | 782 mm | 802 mm | 828 mm | 845 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
CXGR Supremo belongs to the Masi Cxgr model. Masi released 9 bikes variations of this model so far. Take a sneak peek at all Masi Cxgr bikes models from 2020, by clicking here.
Model range prices
Masi CXGR Comp 2020 is the most economical model, with a starting price of 1099$. Masi CXGR Supremo 2020 on the other hand costs 1949$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Masi CXGR Supremo price was 1949$. Doing a quick comparison, we notice that CXGR Supremo price is 26.32% lower than the average cost of a Gravel bike.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the CXGR Supremo bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Masi CXGR Supremo has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
