Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Masi Race Tuned Carbon MCX Textreme Carbon, Di2 Compatible, BB86, Internal Routing, 1.5" Tapered Headtube & Direct Mount Brakes
Suspension Fork
Masi Race Tuned Carbon MCX Monocoque Carbon, Direct Mount Brake
Drivetrain
Rear Derailleur
Shimano Ultegra 6870 11-spd
Front Derailleur
Shimano Ultegra 6870
Shift Levers
Shimano Ultegra 6870 11-spd
Cassette
Shimano 6800 11-28t, 11-spd
Crank
Rotor 3D30, 52/36t
Bottom Bracket
Enduro Dual-Row Bearing BB86
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Dt Swiss R522 Wheelset: Straigh-Pull Dt Hubs, 24/28h
Tires
Clement Strada LGG 25c 60Tpi Folding
Brakes
Brakes
Shimano Ultegra Direct Mount Dual Pivot
Brake Levers
Shimano Ultegra 6870
Cockpit
Stem
Ritchey Wcs C220 Stem
Handlebar
Ritchey Wcs Evocurve 31.8 Alloy
Headset
FSA No.42; Orbit C-40 Sealed 1-1/8 ACB Top, 1.5" Industrial Sealed Bottom
Seat
Saddle
Fizik Antare R5
Seatpost
Ritchey Wcs Alloy 1 Bolt 27.2 X 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.39 mm | 1.42 mm | 1.41 mm | 1.42 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 569 mm | 575 mm | 586 mm | 594 mm | 618 mm | 633 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 59 mm | 56 mm | 55 mm | 58 mm | 58 mm |
| Stack | 504 mm | 525 mm | 545 mm | 567 mm | 584 mm | 603 mm |
| Reach | 378 mm | 382 mm | 391 mm | 400 mm | 415 mm | 424 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 966 mm | 972 mm | 983 mm | 991 mm | 1016 mm | 1031 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 714 mm | 746 mm | 766 mm | 799 mm | 819 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
Model Overview
Evoluzione Ultegra Di2 is a Masi Evoluzione model. 16 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Masi Evoluzione 105 2017 is the most economical model, with a starting price of 2169$. Masi Evoluzione Ultegra Di2 2017 on the other hand costs 4459$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2017 and its price was 4459$. Doing a quick comparison, we notice that Evoluzione Ultegra Di2 price is 33.1% higher than the average cost of a Race bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Evoluzione Ultegra Di2 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Evoluzione Ultegra Di2 2017 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Evoluzione Ultegra Di2 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 152 cm – 196 cm (4.99 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
