Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Masi Comfort Tuned Carbon MC9 Carbon, Di2 Compatible, BB86, Internal Routing, 1.5" Tapered Headtube & Flat-Mount Disc Brakes
Suspension Fork
New Masi Comfort Tuned MC9 Carbon Tapered 1.5" Steerer, 12mm Thru-Axle, Flat Mount Disc Brake, w/ Removable Fender Mounts
Drivetrain
Rear Derailleur
Shimano 105 5800 11-spd
Front Derailleur
Shimano 105
Shift Levers
Shimano Rs505 11-spd, Mechanical Shift / Hydraulic Disc Brake
Cassette
Shimano 5800 11-32t, 11-spd
Crank
Praxis Works Alba Compact 50/34t
Bottom Bracket
Praxis Works M30 By Enduro
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Stans Notubes Radler Disc Rims, Alloy 28h 12mm Thru-Axle Centerlock Hubs w/Alloy TA
Tires
Clement Strada LGG 28c 60Tpi Folding
Brakes
Brakes
Shimano Br-Rs505 Flat Mount Hydraulic 160F/160R
Brake Levers
Shimano Rs505 Hydraulic
Cockpit
Stem
New Brev. M 3D Forged Flip/Flop Stem
Handlebar
New Brev. M 31.8 Alloy Bar
Headset
FSA No.42; Orbit C-40 Sealed 1-1/8 , 1.5" ACB Bearings
Seat
Saddle
New Masi Scs
Seatpost
New Brev. M 3D Forged Alloy 27.2 X 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.5 mm | 1.55 mm | 1.57 mm | 1.6 mm | 1.58 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 268 mm | 268 mm | 271 mm |
| Front Center | 578 mm | 579 mm | 580 mm | 590 mm | 598 mm | 618 mm |
| Rake | 50 mm | 45 mm | 45 mm | 40 mm | 40 mm | 40 mm |
| Trail | 64 mm | 63 mm | 60 mm | 64 mm | 65 mm | 66 mm |
| Stack | 526 mm | 550 mm | 568 mm | 587 mm | 606 mm | 622 mm |
| Reach | 359 mm | 367 mm | 366 mm | 375 mm | 378 mm | 393 mm |
| Top Tube Length | 511 mm | 526 mm | 541 mm | 556 mm | 576 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 430 mm | 465 mm | 500 mm | 535 mm | 555 mm | 585 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 988 mm | 989 mm | 991 mm | 1002 mm | 1010 mm | 1031 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 70 mm | 68 mm | 68 mm | 65 mm |
| Standover Height | 725 mm | 754 mm | 784 mm | 811 mm | 826 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
Vivo Tre is a Masi Vivo model. Masi released 7 bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Masi Vivo Tre 2017 is the cheapest bike model and costs 2499$. Masi Vivo Quattro 2017 is the most expensive one and costs 3049$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2017 and its price was 2499$. Doing a quick comparison, we notice that Vivo Tre price is 6.52% more expensive than the average cost of an Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Vivo Tre has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Vivo Tre bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Masi Vivo Tre is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Masi Vivo Tre bike has 6 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
