Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dedacciai custom-shaped performance Aluminium.
Suspension Fork
RangeFinder AS carbon fork which is custom-tuned for the Bokeh. Features pannier & ‘rando’ style rack mounts, triple accessory mounts, Ø12mm Thru-axle, 160/180mm flat-mount.
Drivetrain
Shift Levers
SRAM Force AXS 12spd.
Cassette
SRAM XG-1271 10-44T
Crank
SRAM Force 1 XPLR 42T
Chain
SRAM Force 12spd D1
Wheels
Rims
HUNT Four Season Gravel Disc X-Wide / Mason X HUNT 650B AdventureSport Disc. Other models available.
Tires
Choice of Schwalbe, Panaracer, WTB, Rene Herse
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
DEDA Superzero.
Handlebar
Deda Gravel100, Ritchey Venturemax, others available.
Headset
DEDA Low profile integrated headset. Chris King upgrades available.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.49 mm | 1.49 mm | 1.52 mm | 1.52 mm | 1.49 mm | 1.53 mm | 1.58 mm |
| Front Center | 590 mm | 590 mm | 602 mm | 604 mm | 610 mm | 620 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 47 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 67 mm | 67 mm | 61 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Stack | 531.1 mm | 532.9 mm | 549 mm | 563.1 mm | 574.5 mm | 582.9 mm | 602 mm | 625.7 mm |
| Reach | 354.9 mm | 358.5 mm | 369 mm | 371.2 mm | 378.4 mm | 390.2 mm | 394.1 mm | 396.4 mm |
| Top Tube Length | 510.9 mm | 514.9 mm | 530.9 mm | 546 mm | 556.4 mm | 575.8 mm | 585.7 mm | 595.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 155 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1008 mm | 1016 mm | 1023 mm | 1029 mm | 1040 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 759 mm | 776 mm | 794 mm | 809 mm | 826 mm | 845 mm | 866 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
Bokeh 3 Force XPLR completes the Mason Bokeh model. Mason launched 30 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Mason Bokeh 3 GRX 810 11 Speed 2023 is the most economical model, with a starting price of 3467$. Mason Bokeh Ti GRX Di2 2023 on the other hand costs 7785$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 4987$. Comparing this to the average Gravel bike price, we see that the price is 102.56% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Bokeh 3 Force XPLR 2023 bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
