Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dedacciai custom-shaped performance Aluminium.
Suspension Fork
Mason Parallax2 full carbon thru-axle fork.
Drivetrain
Shift Levers
Campagnolo Ekar Ergopower
Cassette
Campagnolo Ekar 9-42T 13spd. Other options available.
Crank
Campagnolo Ekar 13spd. Carbon 38T, others available.
Chain
Campagnolo C13
Wheels
Rims
HUNT Four Season Gravel Disc X-Wide / Mason X HUNT 650B AdventureSport Disc. Other models available.
Tires
Choice of Schwalbe, Panaracer, WTB.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
DEDA Superzero.
Handlebar
Deda Gravel100, Ritchey Venturemax, others available.
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Terra Argo X5.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.49 mm | 1.49 mm | 1.52 mm | 1.52 mm | 1.49 mm | 1.53 mm | 1.58 mm |
| Front Center | 590 mm | 590 mm | 602 mm | 604 mm | 610 mm | 620 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 47 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 67 mm | 67 mm | 61 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Stack | 531.1 mm | 532.9 mm | 549 mm | 563.1 mm | 574.5 mm | 582.9 mm | 602 mm | 625.7 mm |
| Reach | 354.9 mm | 358.5 mm | 369 mm | 371.2 mm | 378.4 mm | 390.2 mm | 394.1 mm | 396.4 mm |
| Top Tube Length | 510.9 mm | 514.9 mm | 530.9 mm | 546 mm | 556.4 mm | 575.8 mm | 585.7 mm | 595.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 155 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1008 mm | 1016 mm | 1023 mm | 1029 mm | 1040 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 759 mm | 776 mm | 794 mm | 809 mm | 826 mm | 845 mm | 866 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Bokeh Ekar is part of the Mason Bokeh model. 30 bikes variations carry this model name so far. Take a sneak peek at all Mason Bokeh bikes models from 2023, by clicking here.
Model range prices
Mason Bokeh 3 GRX 810 11 Speed 2023 is the cheapest bike model and costs 3467$. Mason Bokeh Ti GRX Di2 2023 is the most expensive one and costs 7785$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4355$. In conclusion, this bike price is 76.89% higher than the price of the average Gravel bike.
Bokeh Ekar components
Fork material
Bokeh Ekar has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Bokeh Ekar model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Mason Bokeh Ekar has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
