Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dedacciai custom-shaped performance Aluminium.
Suspension Fork
Mason Parallax2 full carbon Thru-Axle fork.
Drivetrain
Shift Levers
SRAM Force AXS 12spd.
Cassette
SRAM Force AXS XG1295 10-50
Crank
SRAM Force AXS 1X 42T.
Chain
SRAM Force 12spd.
Wheels
Rims
HUNT Four Season Gravel Disc X-Wide / Mason X HUNT 650B AdventureSport Disc. Other models available.
Tires
Choice of Schwalbe, Panaracer, WTB.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
DEDA Zero100.
Handlebar
Deda Gravel100
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.49 mm | 1.49 mm | 1.52 mm | 1.52 mm | 1.49 mm | 1.53 mm | 1.58 mm |
| Front Center | 590 mm | 590 mm | 602 mm | 604 mm | 610 mm | 620 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 47 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 67 mm | 67 mm | 61 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Stack | 531.1 mm | 532.9 mm | 549 mm | 563.1 mm | 574.5 mm | 582.9 mm | 602 mm | 625.7 mm |
| Reach | 354.9 mm | 358.5 mm | 369 mm | 371.2 mm | 378.4 mm | 390.2 mm | 394.1 mm | 396.4 mm |
| Top Tube Length | 510.9 mm | 514.9 mm | 530.9 mm | 546 mm | 556.4 mm | 575.8 mm | 585.7 mm | 595.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 155 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1008 mm | 1016 mm | 1023 mm | 1029 mm | 1040 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 759 mm | 776 mm | 794 mm | 809 mm | 826 mm | 845 mm | 866 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Bokeh Force AXS 1X belongs to the Mason Bokeh model. Mason released 30 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Mason Bokeh 3 GRX 810 11 Speed 2023 is the cheapest bike model and costs 3467$. Mason Bokeh Ti GRX Di2 2023 is the most expensive one and costs 7785$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Mason Bokeh Force AXS 1X price was 5139$. If we compare this with the average Gravel bike cost we notice that the price is 108.73% higher.
Bokeh Force AXS 1X components
Fork material
Bokeh Force AXS 1X has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Bokeh Force AXS 1X are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Bokeh Force AXS 1X comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
