Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dedacciai custom-shaped performance Aluminium.
Suspension Fork
Mason Parallax2 full carbon Thru-Axle fork.
Drivetrain
Shift Levers
SRAM Force AXS 12spd.
Cassette
SRAM XG-1271 10-44T
Crank
SRAM Force 1 XPLR 42T
Chain
SRAM Force 12spd D1
Wheels
Rims
HUNT Four Season Gravel Disc X-Wide / Mason X HUNT 650B AdventureSport Disc. Other models available.
Tires
Choice of Schwalbe, Panaracer, WTB, Rene Herse.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Deda Superzero.
Handlebar
Deda Gravel100, Ritchey Venturemax, others available.
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.49 mm | 1.49 mm | 1.52 mm | 1.52 mm | 1.49 mm | 1.53 mm | 1.58 mm |
| Front Center | 590 mm | 590 mm | 602 mm | 604 mm | 610 mm | 620 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 47 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 67 mm | 67 mm | 61 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Stack | 531.1 mm | 532.9 mm | 549 mm | 563.1 mm | 574.5 mm | 582.9 mm | 602 mm | 625.7 mm |
| Reach | 354.9 mm | 358.5 mm | 369 mm | 371.2 mm | 378.4 mm | 390.2 mm | 394.1 mm | 396.4 mm |
| Top Tube Length | 510.9 mm | 514.9 mm | 530.9 mm | 546 mm | 556.4 mm | 575.8 mm | 585.7 mm | 595.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 155 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1008 mm | 1016 mm | 1023 mm | 1029 mm | 1040 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 759 mm | 776 mm | 794 mm | 809 mm | 826 mm | 845 mm | 866 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Bokeh Force XPLR belongs to the Mason Bokeh model. 30 bikes variations carry this model name so far. You can easily view all of the Mason Bokeh bikes models from 2023, here.
Model range prices
Mason Bokeh 3 GRX 810 11 Speed 2023 is the most affordable bike of this model and has a price of 3467$. On the other hand, Mason Bokeh Ti GRX Di2 2023, is the most expensive and costs 7785$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4896$. Comparing the average cost of a Gravel bike to this one, you will see that Bokeh Force XPLR price is 98.86% more expensive.
Bokeh Force XPLR components
Fork material
Bokeh Force XPLR has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Mason Bokeh Force XPLR 2023, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
