Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Exclusive, Mason tooled, Dedacciai custom-formed Titanium tubeset
Suspension Fork
Mason Parallax full carbon UD Thru-axle/Flat-mount fork.
Drivetrain
Shift Levers
SRAM Force 1X.
Cassette
SRAM XG-1175.
Crank
SRAM Force 1X 42T.
Chain
SRAM PC1170.
Wheels
Rims
MASON X Hunt 650B AdventureSport Disc Wheelset as standard, many more choices available.
Tires
Panaracer Comet Hardpack 27.5" x 2.0. as standard, many more choices available.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Deda Superzero.
Handlebar
Deda Superzero Alloy.
Headset
DEDA Low profile, integrated headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.49 mm | 1.49 mm | 1.52 mm | 1.52 mm | 1.49 mm | 1.53 mm | 1.58 mm |
| Front Center | 590 mm | 590 mm | 602 mm | 604 mm | 610 mm | 620 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 47 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 67 mm | 67 mm | 61 mm | 58 mm | 55 mm | 55 mm | 55 mm |
| Stack | 531.1 mm | 532.9 mm | 549 mm | 563.1 mm | 574.5 mm | 582.9 mm | 602 mm | 625.7 mm |
| Reach | 354.9 mm | 358.5 mm | 369 mm | 371.2 mm | 378.4 mm | 390.2 mm | 394.1 mm | 396.4 mm |
| Top Tube Length | 510.9 mm | 514.9 mm | 530.9 mm | 546 mm | 556.4 mm | 575.8 mm | 585.7 mm | 595.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 155 mm | 165 mm | 185 mm | 210 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1008 mm | 1008 mm | 1016 mm | 1023 mm | 1029 mm | 1040 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 759 mm | 776 mm | 794 mm | 809 mm | 826 mm | 845 mm | 866 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
Bokeh Ti Force 1X completes the Mason Bokeh model. Mason launched 30 bikes of this model so far. Take a sneak peek at all Mason Bokeh bikes models from 2023, by clicking here.
Model range prices
Mason Bokeh 3 GRX 810 11 Speed 2023 is the most affordable bike of this model and has a price of 3467$. On the other hand, Mason Bokeh Ti GRX Di2 2023, is the most expensive and costs 7785$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 7092$. In conclusion, this bike price is 188.06% more expensive than the price of the average Gravel bike.
Bokeh Ti Force 1X components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Bokeh Ti Force 1X bike is equipped with the aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Mason Bokeh Ti Force 1X has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
