Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dedacciai, custom formed, triple-butted performance Aluminium frame.
Suspension Fork
Mason Aperture2, thru-axle/flat-mount, full carbon fork.
Drivetrain
Shift Levers
SRAM Red AXS Wireless
Cassette
SRAM Red AXS XG-1290 10-33
Crank
SRAM Red 48/35 2X / 46T 1X
Chain
SRAM Red AXS Chain D1
Wheels
Rims
MASON x HUNT 4Season V3 Disc, other options configurable.
Tires
Schwalbe, G-One 30mm or Pro-One 28mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
DEDA Superzero.
Handlebar
DEDA Superzero Carbon
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Tempo Argo R3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.45 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 590 mm | 595 mm | 600 mm | 610 mm | 615 mm | 620 mm | 630 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 66 mm | 66 mm | 66 mm | 63 mm | 63 mm | 60 mm |
| Stack | 527.1 mm | 538.3 mm | 547.8 mm | 560.5 mm | 574.7 mm | 586.1 mm | 594.1 mm | 615.1 mm |
| Reach | 364.7 mm | 375.6 mm | 377.5 mm | 378 mm | 383.3 mm | 389.7 mm | 391.8 mm | 400.5 mm |
| Top Tube Length | 514 mm | 527.8 mm | 532.4 mm | 546.5 mm | 556.1 mm | 576.3 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 155 mm | 170 mm | 180 mm | 190 mm | 210 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 984 mm | 994 mm | 999 mm | 1004 mm | 1014 mm | 1019 mm | 1025 mm | 1035 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 71 mm | 71 mm | 71 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 751 mm | 765 mm | 782 mm | 799 mm | 813 mm | 828 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Definition Red AXS belongs to the Mason Definition model. Mason released 18 bikes variations of this model so far. You can easily view all of the Mason Definition bikes models from 2023, here.
Model range prices
Mason Definition 105 R7100 12 Speed 2023 is the most affordable bike of this model and has a price of 3406$. On the other hand, Mason Definition Red AXS 2023, is the most expensive and costs 7353$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Mason released this model in 2023, its price was 7353$. If we compare this with the average Endurance bike cost we notice that the price is 213.43% more expensive.
Definition Red AXS components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Mason Definition Red AXS 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
