mason InSearchOf GX Eagle AXS 2022
2022 Road
Estimate price |
5,152$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Rival AXS, GX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
42cm
151cm - 164cm
46cm
161cm - 174cm
50cm
170cm - 183cm
54cm
180cm - 190cm
58cm
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom-formed Progressive-butted Dedacciai / Reynolds Steel tubeset.
Suspension Fork
Exclusive 'HotShoe' Carbon, ThruAxle, Flat-mount fork with multiple accessory mounts.
Drivetrain
Shift Levers
SRAM Rival AXS Wireless
Cassette
SRAM XG1275 10-52T
Crank
SRAM GX Eagle 34T Boost
Chain
SRAM Eagle 12spd
Wheels
Rims
Mason X HUNT 'The Search'' Dynamo 29" / HUNT 27.5" TrailWide
Tires
WTB Ranger 29 x 2.4 / Ranger 27.5 x 2.8 / Schwalbe choices.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail
Handlebar
Ritchey Venturemax Comp
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Terra Argo X5
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 54cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.64 mm | 1.64 mm | 1.64 mm |
| Front Center | 628.3 mm | 640.7 mm | 648 mm | 656 mm | 666.3 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm | 67 mm |
| Stack | 609 mm | 617.4 mm | 626.8 mm | 636.1 mm | 657.5 mm |
| Reach | 369.6 mm | 378.7 mm | 382.4 mm | 387 mm | 400.4 mm |
| Top Tube Length | 545.7 mm | 557.1 mm | 563.5 mm | 570.6 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1065 mm | 1078 mm | 1085 mm | 1093 mm | 1104 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 75 mm | 75 mm | 73 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 161 cm | 170 cm | 180 cm | 188 cm |
| Rider Max Height | 164 cm | 174 cm | 183 cm | 190 cm | 198 cm |
About this model
InSearchOf GX Eagle AXS is a Mason Insearchof model. Mason launched 10 bikes of this model so far. You can easily view all of the Mason Insearchof bikes models from 2022, here.
Model range prices
Mason InSearchOf Rival 1X 2022 is the cheapest bike model and costs 3819$. Mason InSearchOf GR|XT Di2 2022 is the most expensive one and costs 5224$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2022 and its price was 4683$. Doing a quick comparison, we notice that InSearchOf GX Eagle AXS price is 90.21% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
InSearchOf GX Eagle AXS has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Mason InSearchOf GX Eagle AXS 2022, has a aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
InSearchOf GX Eagle AXS comes in 5 sizes, that range from 151 cm – 198 cm (4.95 ft – 6.5 ft). In short, you can easily find one that suits you.
