Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset GX Eagle AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 170cm
MD
168cm - 180cm
LG
178cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full UK construction, custom shaped and formed Dedacciai Zero/Uno & Reynolds steel tubeset.
Suspension Fork
RockShox SID Ultimate 120mm.
Drivetrain
Shift Levers
SRAM GX AXS Eagle Wireless.
Cassette
SRAM XG-1275 10-52T.
Crank
SRAM GX Eagle Alloy 32T Chainset.
Chain
SRAM GX Eagle 12spd.
Wheels
Rims
Choice of HUNT MTB wheelsets.
Tires
Choice of Maxxis, Schwalbe and Vittoria.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail WCS.
Handlebar
Renthal FatBar 2
Grips
Ergon GA2.
Headset
Deda EC/ZS44mm sealed bearing headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
PNW Loam 31.6 dropper post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 722 mm | 751.9 mm | 775.8 mm | 803 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 117 mm | 117 mm | 117 mm | 117 mm |
| Stack | 605.3 mm | 614.4 mm | 623.5 mm | 632.7 mm |
| Reach | 421 mm | 446.2 mm | 466 mm | 489.3 mm |
| Top Tube Length | 572.7 mm | 601 mm | 623.4 mm | 649 mm |
| Seat Tube Angle | 75.2 ° | 75.12 ° | 75.11 ° | 75.37 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1146 mm | 1175 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 170 cm | 180 cm | 188 cm | 198 cm |
About this model
RAW GX AXS is part of the Mason Raw model. Mason released 6 bikes variations of this model so far. Take a sneak peek at all Mason Raw bikes models from 2022, by clicking here.
Model range prices
Mason RAW SLX 2022 is the cheapest bike model and costs 4616$. Mason RAW GX AXS 2022 is the most expensive one and costs 5711$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Mason released this model in 2022, its price was 5711$. In conclusion, this bike price is 106.77% more expensive than the price of the average Trail bike.
Overview of components
Fork
The RAW GX AXS comes factory-installed with the RockShox SID Ultimate fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on RAW GX AXS are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Mason RAW GX AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Mason RAW GX AXS bike has 4 sizes, in the range of 162 cm – 198 cm (5.31 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Mason RAW GX AXS includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
