Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset GX Eagle AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 170cm
MD
168cm - 180cm
LG
178cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full UK construction, custom shaped and formed Dedacciai Zero/Uno & Reynolds steel tubeset.
Suspension Fork
RockShox SID Ultimate 120mm.
Drivetrain
Shift Levers
SRAM GX AXS Eagle Wireless.
Cassette
SRAM XG-1275 10-52T.
Crank
SRAM GX Eagle Alloy 32T Chainset.
Chain
SRAM GX Eagle 12spd.
Wheels
Rims
Choice of HUNT MTB wheelsets.
Tires
Choice of Maxxis, Schwalbe and Vittoria.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail WCS.
Handlebar
Renthal FatBar 2
Grips
Ergon GA2.
Headset
Deda EC/ZS44mm sealed bearing headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
PNW Loam 31.6 dropper post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 722 mm | 751.9 mm | 775.8 mm | 803 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 117 mm | 117 mm | 117 mm | 117 mm |
| Stack | 605.3 mm | 614.4 mm | 623.5 mm | 632.7 mm |
| Reach | 421 mm | 446.2 mm | 466 mm | 489.3 mm |
| Top Tube Length | 572.7 mm | 601 mm | 623.4 mm | 649 mm |
| Seat Tube Angle | 75.2 ° | 75.12 ° | 75.11 ° | 75.37 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1146 mm | 1175 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 170 cm | 180 cm | 188 cm | 198 cm |
Model Overview
RAW GX AXS is part of the Mason Raw model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Mason RAW SLX 2023 is the most affordable bike of this model and has a price of 4616$. On the other hand, Mason RAW GX AXS 2023, is the most expensive and costs 5711$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5711$. In conclusion, this bike price is 106.77% more expensive than the price of the average Trail bike.
RAW GX AXS components
Fork
The RAW GX AXS comes factory-installed with the RockShox SID Ultimate fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Mason RAW GX AXS 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RAW GX AXS comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 162 cm – 198 cm (5.31 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Mason model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
