Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Resolution Columbus Spirit/Life performance steel ThruAxle frame.
Suspension Fork
Mason Aperture2 full carbon ThruAxle fork.
Drivetrain
Shift Levers
SRAM Force1 HRD.
Cassette
SRAM XG-1175 10:42T.
Crank
SRAM Force 1X 46T.
Chain
SRAM PC1170.
Wheels
Rims
MASON x HUNT 4Season disc wheels.
Tires
Schwalbe, G-One 30mm or Pro-One 28mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Deda Superzero.
Handlebar
Deda Zero2 Alloy.
Headset
DEDA Low profile, carbon top cover, integrated headset.
Seat
Saddle
Fizik Tempo Argo R3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.45 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 590 mm | 595 mm | 600 mm | 610 mm | 615 mm | 620 mm | 630 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 66 mm | 66 mm | 66 mm | 63 mm | 63 mm | 60 mm |
| Stack | 527.1 mm | 538.3 mm | 547.8 mm | 560.5 mm | 574.7 mm | 586.1 mm | 594.1 mm | 615.1 mm |
| Reach | 364.7 mm | 375.6 mm | 377.5 mm | 378 mm | 383.3 mm | 389.7 mm | 391.8 mm | 400.5 mm |
| Top Tube Length | 514 mm | 527.8 mm | 532.4 mm | 546.5 mm | 556.1 mm | 576.3 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 155 mm | 170 mm | 180 mm | 190 mm | 210 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 984 mm | 994 mm | 999 mm | 1004 mm | 1014 mm | 1019 mm | 1025 mm | 1035 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 71 mm | 71 mm | 71 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 751 mm | 765 mm | 782 mm | 799 mm | 813 mm | 828 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Resolution Force 1X is a Mason Resolution model. Mason launched 19 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Mason Resolution 105 2022 is the cheapest bike model and costs 3972$. Mason Resolution Dura Ace Di2 2022 is the most expensive one and costs 7475$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Mason released this model in 2022, its price was 4580$. Comparing this to the average Endurance bike price, we see that the price is 95.23% higher.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Resolution Force 1X are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Mason Resolution Force 1X is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
