mason Resolution Ultegra Di2 2023
2023 Road
Estimate price |
5,841$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Resolution Columbus Spirit/Life performance steel frame.
Suspension Fork
Mason Aperture full carbon fork.
Drivetrain
Shift Levers
Shimano Ultegra R8170 Di2 Electronic. 12spd.
Cassette
Shimano 12-speed HYPERGLIDE+ cassettes in 11-30 and 11-34 ratios.
Crank
Shimano Ultegra R8100 50/34.
Chain
Shimano Ultegra R8100 / XT 12spd.
Wheels
Rims
MASON x HUNT 4Season V3 Disc wheels.
Tires
Schwalbe G-One 30mm or Pro-One 28mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Deda Zero100 black on black. 82º. 126g.
Handlebar
DEDA ZERO100 black on black. 248g.
Headset
DEDA Low profile, carbon top cover, integrated headset.
Seat
Saddle
Fizik Tempo Argo R3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.45 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 590 mm | 595 mm | 600 mm | 610 mm | 615 mm | 620 mm | 630 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 66 mm | 66 mm | 66 mm | 63 mm | 63 mm | 60 mm |
| Stack | 527.1 mm | 538.3 mm | 547.8 mm | 560.5 mm | 574.7 mm | 586.1 mm | 594.1 mm | 615.1 mm |
| Reach | 364.7 mm | 375.6 mm | 377.5 mm | 378 mm | 383.3 mm | 389.7 mm | 391.8 mm | 400.5 mm |
| Top Tube Length | 514 mm | 527.8 mm | 532.4 mm | 546.5 mm | 556.1 mm | 576.3 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 155 mm | 170 mm | 180 mm | 190 mm | 210 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 984 mm | 994 mm | 999 mm | 1004 mm | 1014 mm | 1019 mm | 1025 mm | 1035 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 71 mm | 71 mm | 71 mm | 70 mm | 70 mm |
| Standover Height | 736 mm | 751 mm | 765 mm | 782 mm | 799 mm | 813 mm | 828 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Resolution Ultegra Di2 belongs to the Mason Resolution model. Mason released 19 bikes variations of this model so far. Take a sneak peek at all Mason Resolution bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Mason Resolution 105 7100 12 Speed 2023 has a starting price of 3649$. Mason Resolution Dura Ace Di2 2023 on the other hand is the most expensive at 7475$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5310$. Comparing the average cost of an Endurance bike to this one, you will see that Resolution Ultegra Di2 price is 126.34% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Mason Resolution Ultegra Di2 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Mason Resolution Ultegra Di2 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
