Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
48cm
152cm - 160cm
50cm
157cm - 168cm
52cm
163cm - 172cm
54cm
170cm - 180cm
56cm
175cm - 185cm
58cm
180cm - 188cm
60cm
185cm - 193cm
62cm
191cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SLR custom formed, TIG welded, Dedacciai Zero/Uno.
Suspension Fork
Mason Rangefinder AR custom tuned, full carbon, thru-axle fork with rack-mounts.
Drivetrain
Shift Levers
SRAM Force AXS 12spd.
Cassette
SRAM Force XG-1270 10-33 12spd.
Crank
SRAM Force AXS 12spd. 48/35
Chain
SRAM Force AXS 12spd. FlatTop
Wheels
Rims
MASON x HUNT AllRoad Disc wheels. Others available.
Tires
Choice of premium Schwalbe & Continental Tubeless tyres. 30mm G-One Standard.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Deda Zero100 black on black. 82º. 126g.
Handlebar
Deda Zero100 black on black. 82º. 126g.
Headset
Deda IN-5 Low profile integrated headset.
Seat
Saddle
Fizik Tempo Argo R3.
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.55 mm | 1.55 mm | 1.58 mm | 1.6 mm | 1.6 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 276 mm | 276 mm | 276 mm | 279 mm | 279 mm |
| Front Center | 592.7 mm | 601 mm | 608.1 mm | 614 mm | 622.7 mm | 628.3 mm | 641.7 mm | 652.6 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 71 mm | 71 mm | 71 mm | 67 mm | 64 mm | 130 mm |
| Stack | 550 mm | 559.4 mm | 570.8 mm | 583 mm | 597.2 mm | 608.6 mm | 617.2 mm | 636.1 mm |
| Reach | 355 mm | 360 mm | 368.1 mm | 369.3 mm | 373 mm | 380 mm | 395.4 mm | 400 mm |
| Top Tube Length | 511.5 mm | 519.1 mm | 530.1 mm | 545.3 mm | 553.2 mm | 574.4 mm | 592.2 mm | 602.8 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 140 mm | 150 mm | 165 mm | 180 mm | 190 mm | 200 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1006 mm | 1014 mm | 1021 mm | 1028 mm | 1037 mm | 1042 mm | 1057 mm | 1068 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 733 mm | 753 mm | 773 mm | 790 mm | 806 mm | 822 mm | 840 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 157 cm | 163 cm | 170 cm | 175 cm | 180 cm | 185 cm | 191 cm |
| Rider Max Height | 160 cm | 168 cm | 172 cm | 180 cm | 185 cm | 188 cm | 193 cm | 198 cm |
Model Overview
SLR Force AXS belongs to the Mason Slr model. Mason launched 5 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Mason SLR GRX 2023 has a starting price of 4987$. Mason SLR Force AXS 2023 on the other hand is the most expensive at 6325$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6325$. Doing a quick comparison, we notice that SLR Force AXS price is 156.9% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
SLR Force AXS has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the SLR Force AXS model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Mason SLR Force AXS is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 8 sizes. They vary from 152 cm – 198 cm (4.99 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
