Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XT, Deore -
Suspension Full -
Motor Shimano 85Nm hub-drive -
Battery Integrated LI-ION Battery, 762 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Crave Full Carbon FSC Technology Carbon Swingarm, EP8 Specific Boost 12x148, Wheel travel: 160 mm, Tire clearance 29 x 2.6
Suspension Fork
Fox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake
Rear Shock
Fox FLOAT X, Factory Series, Kashima 2pos-adj, Trunnion, Evol LV, 205x65
Drivetrain
Rear Derailleur
Shimano XT 12s
Shift Levers
Shimano Deore 12s
Cassette
Shimano Deore 12s 10-51t
Crank
Shimano 36t
Wheels
Front Hub
Boost System 15x110 12x148, E-Bike+
Rear Hub
Boost System 15x110 12x148, E-Bike+
Rims
29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready
Tires
Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALL
Brakes
Brakes
Shimano XT M8020 Hydraulic disc 4-Piston, 203mm
Cockpit
Stem
3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º
Handlebar
Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º
Headset
Integrated Full Internal Cable Routing
Seat
Saddle
Sellie Italia Model X Superflow
Seatpost
Fox Transfer Kashima 31,6mm telescopic seat post, remote adjustment
Motor & Battery
Motor
Shimano EP801 / 85 Nm
Battery
Integrated LI-ION Battery, 762 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.362 mm | 1.323 mm |
| Stack | 615 mm | 625 mm | 647 mm |
| Reach | 435 mm | 459 mm | 489 mm |
| Top Tube Length | 588 mm | 615 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 420 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 135 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1215 mm | 1244 mm | 1284 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
CRAVE CRB 03 completes the Megamo E Crave model. 38 e-bikes variations carry this model name so far. Take a sneak peek at all Megamo E Crave e-bikes models from 2023, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
CRAVE CRB 03 components
Fork
Megamo CRAVE CRB 03 2023 e-bike is equipped with the Fox Factory Float 38 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox FLOAT X rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Megamo CRAVE CRB 03 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The CRAVE CRB 03 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Megamo CRAVE CRB 03 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
