Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel AL 6061 Triple Butted, Hydroformed Technology, Internal Cable Routing, Flat Mount Disc 12x142
Suspension Fork
Carbon Disc Fork, Internal Cable Routing, Flat Mount Disc 12x100
Drivetrain
Rear Derailleur
Shimano RX-400 10s
Shift Levers
Shimano RX-400 Flat mount hydraulic disc
Cassette
Shimano HG50 11-36t 10s
Crank
FC 46-30t
Wheels
Front Hub
Formula CL712 - RXC400 Alloy 12x100 / 12x142
Rear Hub
Formula CL712 - RXC400 Alloy 12x100 / 12x142
Rims
Megamo Gravel GR 700 - TLR
Tires
WTB Riddler 700 x 45c Tan Sidewall
Brakes
Brakes
Shimano RX-400 Flat mount hydraulic disc
Cockpit
Stem
Megamo FOV
Handlebar
Megamo Specific Gravel HB FOV Compact
Headset
FSA Orbit - Z 1-1/8" Semi Integrated
Seat
Saddle
Sellie Italia Model X Superflow
Seatpost
Megamo 27,2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.54 mm | 1.52 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 9920580 mm | 606 mm | 631 mm | 657 mm | mm |
| Rake | 9321810 mm | 70 mm | 74 mm | 75 mm | mm |
| Trail | -9919940 mm | 49 mm | 42 mm | 41 mm | mm |
| Stack | 527 mm | 548 mm | 568 mm | 598 mm | 630 mm |
| Reach | 345 mm | 356 mm | 374 mm | 390 mm | 405 mm |
| Top Tube Length | 492 mm | 513 mm | 543 mm | 573 mm | 598 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 415 mm | 500 mm | 530 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 175 mm | 210 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
JAKAR 30 belongs to the Megamo Jakar model. There are 8 bikes that carry this model name. Take a sneak peek at all Megamo Jakar bikes models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
JAKAR 30 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The JAKAR 30 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Megamo JAKAR 30 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
