Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset CUES, FSA -
Suspension Rigid -
Motor 200W 65Nm mid-drive -
Battery integrated (Li-Ion) 36v - 14 Ah - 504 Wh -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium frame, Central motor, Hydroformed Technology, Internal Cable Routing, Flat Mount Disc 12x142
Suspension Fork
Carbon Disc Fork, Internal Cable Routing, Flat Mount Disc 12x100
Drivetrain
Rear Derailleur
Shimano CUES 9s
Shift Levers
Shimano CUES 9s
Crank
FSA 38T
Wheels
Rims
Megamo GR 700 - TLR
Tires
WTB Riddler 700 x 45c Tan Sidewall
Brakes
Brakes
Mechanical Disc
Cockpit
Stem
Megamo FOV
Handlebar
Megamo FOV Compact
Headset
FSA Tapered
Seat
Saddle
Sellie Italia Model X Superflow
Seatpost
Megamo 30,9mm
Motor & Battery
Motor
Megamo central motor 200W 65Nm
Battery
integrated (Li-Ion) 36v - 14 Ah - 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.558 mm | 1.515 mm | 1.654 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm |
| Front Center | 607 mm | 611 mm | 615 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 61 mm | 54 mm |
| Stack | 581.05 mm | 584.99 mm | 636.6 mm |
| Reach | 372.84 mm | 386.16 mm | 384.77 mm |
| Top Tube Length | 540 mm | 560 mm | 580 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° |
| Head Tube Length | 160 mm | 160 mm | 210 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1053 mm | 1058 mm | 1062 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
KANSAS CITY is part of the Megamo E Kansas model. Megamo released 4 e-bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel e-bikes
According to our calculations, the average cost of a Gravel e-bike that is reliable is 3642$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the KANSAS CITY e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Megamo KANSAS CITY e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
