Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12x142
Suspension Fork
Carbon Advanced Composite fork, Full Internal Cable Routing, Flat Mount Disc Brakes 12x100
Drivetrain
Rear Derailleur
SRAM Red AXS 12s
Shift Levers
SRAM Red AXS 12s
Cassette
SRAM Red AXS 12s 10-33t
Crank
SRAM Red AXS 12s 48-35t
Wheels
Front Hub
DT Swiss ARC 1100 50 / Mavic Cosmic SLR 45
Rear Hub
DT Swiss ARC 1100 50 / Mavic Cosmic SLR 45
Rims
DT Swiss ARC 1100 50 / Mavic Cosmic SLR 45
Tires
Vittoria Rubino IV G2.0 TLR
Brakes
Brakes
SRAM Red AXS 12s
Cockpit
Stem
Integrated Internal Routing
Handlebar
Megamo Fov Compact
Headset
Integrated Internal Routing, 3 positions, 3 different heights
Seat
Saddle
Selle San Marco Shortfit Dynamic Wide Manganese Carbon Fiber Reinforced 250 x 144mm
Seatpost
Megamo 27,2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.415 mm | 1.415 mm | 1.42 mm | 1.425 mm | 1.432 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Stack | 505 mm | 522 mm | 541 mm | 560 mm | 580 mm |
| Reach | 357 mm | 369 mm | 381 mm | 393 mm | 405 mm |
| Top Tube Length | 507 mm | 523 mm | 541 mm | 559 mm | 576 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 103 mm | 116 mm | 135 mm | 156 mm | 176 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
RAISE AXS 01 is part of the Megamo Raise model. Megamo launched 24 bikes of this model so far. You can easily view all of the Megamo Raise bikes models from 2021, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
RAISE AXS 01 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the RAISE AXS 01 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RAISE AXS 01 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
RAISE AXS 01 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
