Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor 250W 80Nm mid-drive -
Battery integrated (Li-Ion) 36v - 14 Ah - 504 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Integratted Battery, central motor, tapered 1,5" headtube
Suspension Fork
Suntour XCM HLO, travel 100mm, tapered headtube
Drivetrain
Rear Derailleur
Shimano Alivio 9s
Shift Levers
Shimano Altus 9s
Cassette
Shimano Altus 9s 11-36T
Crank
FSA 36T 104c
Wheels
Front Hub
Formula
Rear Hub
Formula
Rims
XC one doble wall disc
Tires
Maxxis Ikon 29 x 2,2
Brakes
Brakes
Shimano MT200 hydraulic disc 180/180
Cockpit
Stem
3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º
Handlebar
Alloy butted 31,8x720 mm, rise: 12 mm, back sweep: 6º
Headset
FSA tapered
Seat
Saddle
Megamo
Seatpost
Megamo 30,9mm
Motor & Battery
Motor
Megamo mid motor 250W 80Nm
Battery
integrated (Li-Ion) 36v - 14 Ah - 504 Wh
Remote
Megamo LCD screen 5 levels
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.483 mm | 1.522 mm | 1.498 mm |
| Stack | 608 mm | 633 mm | 656 mm |
| Reach | 410 mm | 416 mm | 438 mm |
| Top Tube Length | 580 mm | 600 mm | 630 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 68 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 145 mm | 140 mm | 165 mm |
| Chainstay Length | 470 mm | 485 mm | 485 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
RIDON 10 belongs to the Megamo E Ridon model. Megamo released 14 e-bikes variations of this model so far. You can easily view all of the Megamo E Ridon e-bikes models from 2021, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry e-bikes average price
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Overview of components
Fork
Megamo RIDON 10 2021 e-bike is equipped with the SunTour XCM HLO fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The RIDON 10 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RIDON 10 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
