Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Altus, FSA -
Suspension Hardtail -
Motor 250W 80Nm mid-drive -
Battery Integrated LI-ION Battery, 630 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Integratted Battery, central motor, tapered 1,5" headtube
Suspension Fork
Suntour 32 XCM ATB, 100mm
Drivetrain
Rear Derailleur
Shimano Altus 9s
Shift Levers
Shimano Altus 9s
Crank
FSA 36T 104c
Wheels
Front Hub
Formula
Rear Hub
Formula
Rims
XC one doble wall disc
Tires
Schwalbe Johnny Watts 29x2,35 [M,L] ; Vittoria Mezcal 27,5x2,25 [S]
Brakes
Brakes
Shimano MT200 hydraulic, Rotor disc 180/180mm
Cockpit
Stem
3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º
Handlebar
Alloy butted 31,8x720 mm, rise: 12 mm, back sweep: 6º
Headset
FSA tapered
Seat
Saddle
Megamo Specific E-Bike+ Saddle
Seatpost
Megamo 30,9mm
Motor & Battery
Motor
Megamo Central Motor M-PW 80Nm, 250W, Torque Sensor
Battery
Integrated LI-ION Battery, 630 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
RIDON HT 630 05 is part of the Megamo E Ridon model. Megamo launched 14 e-bikes of this model so far. Take a sneak peek at all Megamo E Ridon e-bikes models from 2023, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry e-bikes average price
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This e-bike has the Suntour XCM fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The RIDON HT 630 05 2023 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Megamo RIDON HT 630 05 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Megamo RIDON HT 630 05 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
