Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Fork SunTour XCM HLO -
Groupset Alivio, Sora -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE TFS
Suspension Fork
SR 29 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M3000
Shift Levers
Shimano Altus rapidfire
Cassette
Shimano HG200-9 11-34
Crank
SR XCM 40-30-22 CG (BSA)
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X9
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA BIG.NINE comp D
Spokes
Black stainless
Tires
Maxxis Ikon 29er 2.2 fold
Brakes
Brakes
Tektro Auriga hydraulic 180 / Tektro Auriga hydraulic 160
Cockpit
Handlebar
MERIDA pro OS 680 R12
Headset
FSA No.572/62BP-1
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA comp SB12 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.6 mm | 1.57 mm | 1.53 mm | 1.49 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 625 mm | 645 mm | 660 mm | 680 mm | 701 mm |
| Rake | 46 mm | 45 mm | 46 mm | 45 mm | 46 mm |
| Trail | 87 mm | 88 mm | 84 mm | 85 mm | 84 mm |
| Stack | 612 mm | 621 mm | 633 mm | 642 mm | 652 mm |
| Reach | 370 mm | 387 mm | 403 mm | 420 mm | 437 mm |
| Top Tube Length | 558 mm | 578 mm | 598 mm | 618 mm | 638 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 381 mm | 446 mm | 484 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1061 mm | 1081 mm | 1096 mm | 1116 mm | 1137 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 695 mm | 746 mm | 781 mm | 819 mm | 861 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE 100 completes the Merida Bignine model. Merida released 236 bikes variations of this model so far. You can easily view all of the Merida Bignine bikes models from 2016, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.7 kg (30.2 lbs), Merida bike is considerably heavier than average. To sum up, it’s 10.48% heavier than the average weight of Crosscountry bikes.
BIG.NINE 100 components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on BIG.NINE 100 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida BIG.NINE 100 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
