Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Suntour XCT
-
Groupset Altus, Tourney -
Suspension Full -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE SPEED, 100 mm suspension travel, material: aluminium, 29x2.25" max. wheelsize, 135x9 mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour XCT30, Coil, 100 mm suspension travel, 29x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M310-8
Front Derailleur
Shimano FD-TY600
Shift Levers
Shimano ST-EF505
Cassette
Sunrace CSM668, 11-32 teeth, 8 speed
Crank
Shimano TY301, 42-34-24 teeth, MAT Aluminium, 170 mm-S, 175 mm-M up
Bottom Bracket
FSA TH-7420ST, 68-124
Chain
KMC Z8.1
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505, 100x9 mm width front hub, 32 spoke holes, Centerlock, 135x9 mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9 mm width front hub, 32 spoke holes, Centerlock, 135x9 mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17 mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1080, 29x2.2", wire
Brakes
Brakes
Tektro M275, hydraulic brake
Cockpit
Handlebar
MERIDA CC, material: aluminium, 690 mm width, 15 mm rise
Headset
FSA NO.10
Seat
Saddle
MERIDA Sport comfort
Seatpost
MERIDA CC, 27.2 mm diameter, 15 mm setback, material: aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.646 mm | 1.61 mm | 1.588 mm | 1.559 mm | 1.532 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 663 mm | 683 mm | 704 mm |
| Rake | 47 mm | 51 mm | 53 mm | 57 mm | 60 mm |
| Trail | 86 mm | 82 mm | 76 mm | 72 mm | 69 mm |
| Stack | 614 mm | 623 mm | 635 mm | 644 mm | 654 mm |
| Reach | 373 mm | 387 mm | 400 mm | 413 mm | 427 mm |
| Top Tube Length | 558 mm | 579 mm | 599 mm | 619 mm | 640 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 382 mm | 448 mm | 486 mm | 532 mm | 583 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1071 mm | 1092 mm | 1106 mm | 1126 mm | 1147 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 698 mm | 755 mm | 789 mm | 829 mm | 869 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE 15 is part of the Merida Bignine model. Merida launched 246 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Merida BIG.NINE 20 2024 is the most affordable bike of this model and has a price of 577$. On the other hand, Merida BIG.NINE XT 2024, is the most expensive and costs 2568$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
BIG.NINE 15 components
Fork
Merida BIG.NINE 15 2024 bike is equipped with the Suntour XCT fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The BIG.NINE 15 2024 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida BIG.NINE 15 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
