Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Fork SunTour XCM HLO -
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE SPEED
Suspension Fork
SR 29 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano Acera-X 8
Front Derailleur
Shimano TY 8s 42
Shift Levers
Shimano Altus rapidfire 3 / Shimano Altus rapidfire 8
Cassette
Sunrace CS8 11-32
Crank
Shimano TY301 42-34-24 CG
Chain
Chain 8s
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA BIG.NINE D
Spokes
stainless silver
Tires
MERIDA 29 2.2
Brakes
Brakes
Tektro MA hydraulic 160
Brake Levers
Tektro M285
Cockpit
Handlebar
MERIDA comp OS 690 R15
Headset
EGG steel-B
Seat
Saddle
MERIDA Sport
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.59 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 663 mm | 683 mm | 704 mm |
| Rake | 45 mm | 46 mm | 46 mm | 45 mm | 46 mm |
| Trail | 88 mm | 87 mm | 84 mm | 85 mm | 84 mm |
| Stack | 613 mm | 622 mm | 634 mm | 643 mm | 653 mm |
| Reach | 374 mm | 391 mm | 407 mm | 424 mm | 441 mm |
| Top Tube Length | 557 mm | 578 mm | 598 mm | 618 mm | 639 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 382 mm | 448 mm | 486 mm | 532 mm | 583 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1070 mm | 1091 mm | 1105 mm | 1125 mm | 1146 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 697 mm | 754 mm | 788 mm | 828 mm | 868 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE 20-D is part of the Merida Bignine model. Merida released 236 bikes variations of this model so far. You can easily view all of the Merida Bignine bikes models from 2017, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 15.6 kg (34.39 lbs), Merida bike is much heavier than average. In short, the average Crosscountry bike weight is 25.81% lower than this one.
Overview of components
Fork
The BIG.NINE 20-D comes factory-installed with the SunTour XCM HLO fork. This has a travel range of mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the BIG.NINE 20-D bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BIG.NINE 20-D comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
