Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Fork SunTour XCM HLO -
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE SPEED
Suspension Fork
SR 29 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano Acera-X
Front Derailleur
Shimano M190
Shift Levers
Shimano EZ fire 3 / Shimano EZ fire 8
Cassette
Sunrace CS8 11-32
Crank
Shimano M131 42-34-24 CG
Bottom Bracket
Cartridge Bearing
Chain
Sunrace 8S
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA BIG.NINE D
Tires
MERIDA 29 2.2
Brakes
Brakes
Promax MTD Mechanical 160
Brake Levers
attached
Cockpit
Handlebar
MERIDA comp OS 680 R15
Headset
EGG steel-B
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.59 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 663 mm | 683 mm | 704 mm |
| Rake | 46 mm | 46 mm | 46 mm | 45 mm | 46 mm |
| Trail | 87 mm | 87 mm | 84 mm | 85 mm | 84 mm |
| Stack | 611 mm | 620 mm | 632 mm | 641 mm | 651 mm |
| Reach | 372 mm | 389 mm | 405 mm | 422 mm | 439 mm |
| Top Tube Length | 557 mm | 577 mm | 597 mm | 617 mm | 647 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 73 ° |
| Seat Tube Length | 380 mm | 445 mm | 483 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1063 mm | 1084 mm | 1098 mm | 1118 mm | 1139 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 693 mm | 750 mm | 783 mm | 823 mm | 864 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Big.Nine 20-MD completes the Merida Bignine model. 236 bikes variations carry this model name so far. Take a sneak peek at all Merida Bignine bikes models from 2015, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Big.Nine 20-MD components
Fork
This bike has the SunTour XCM HLO fork installed. The fork’s travel is mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Big.Nine 20-MD model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Big.Nine 20-MD is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
