Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Suntour RAIDON
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE CF3 III, material: carbon, 29x2.4" max wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour Raidon 34 R-2CR, Air, 100mm suspension travel, Tapered, Remote lockout, 29x2.4" max. wheelsize, 46 mm fork offset
Drivetrain
Rear Derailleur
Shimano Deore M6100, SGS
Shift Levers
Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Shimano Deore MT512, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
Shimano BB-MT-501, 24mm
Chain
KMC X12
Wheels
Front Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP CC II, 25mm inner width, material: aluminium, tubeless ready
Spokes
Black stainless
Tires
Maxxis Rekon Race, 29x2.25", wire
Brakes
Brakes
Shimano MT200, 2 piston
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
Headset
Acros ICR MERIDA INTEGRATED, Upper and lower IPS sealing
Seat
Saddle
MERIDA COMP SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.34 mm | 1.3 mm | 1.27 mm | 1.24 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 701 mm | 721 mm | 745 mm | 768 mm | 791 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 43 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm | 105 mm |
| Stack | 603 mm | 603 mm | 612 mm | 621 mm | 631 mm |
| Reach | 429 mm | 449 mm | 469 mm | 489 mm | 509 mm |
| Top Tube Length | 588 mm | 608 mm | 630 mm | 652 mm | 675 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 427 mm | 430 mm | 433 mm | 436 mm | 439 mm |
| Wheelbase | 1120 mm | 1143 mm | 1170 mm | 1196 mm | 1223 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 701 mm | 701 mm | 707 mm | 728 mm | 749 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE 3000 completes the Merida Bignine model. There are 236 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Merida BIG.NINE TR LIMITED 2024 is the cheapest bike model and costs 1528$. Merida BIG.NINE XT 2024 is the most expensive one and costs 2547$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.31 kg (27.14 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 12.3 kg (27.12 lbs), the BIG.NINE 3000 model is slightly lighter than average. To sum up, it’s 0.08% lighter than the average weight of Crosscountry bikes.
Overview of components
Fork
The fork installed on this bike is the Suntour RAIDON model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on BIG.NINE 3000 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida BIG.NINE 3000 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
