Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE SPEED
Suspension Fork
Suntour XCM 100mm travel with lockout
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano M2000
Shift Levers
Shimano EF505 27 speed EZ-fire shifters
Cassette
Shimano CS-HG200, 9 speed, 11-32 teeth
Crank
Shimano MT100 40-30-22 with chainguard
Chain
KMC M99
Wheels
Front Hub
Shimano TX505 32 hole quick release with centerlock
Rear Hub
Shimano TX505 32 hole quick release with centerlock
Rims
MERIDA aluminium, 32 hole for disc brakes
Spokes
Black steel
Tires
MERIDA K1080 29 * 2.2", wire bead, 30tpi
Brakes
Brakes
Shimano EF505 hydraulic disc brakes with 160mm centerlock rotors
Brake Levers
Shimano EF505
Cockpit
Handlebar
MERIDA Speed Oversize clamp 690mm wide 15mm rise
Headset
MERIDA 2211
Seat
Saddle
MERIDA Sport comfort
Seatpost
MERIDA Speed 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.59 mm | 1.56 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 628 mm | 649 mm | 663 mm | 683 mm | 704 mm |
| Rake | 45 mm | 46 mm | 46 mm | 45 mm | 46 mm |
| Trail | 88 mm | 87 mm | 84 mm | 85 mm | 84 mm |
| Stack | 613 mm | 622 mm | 634 mm | 643 mm | 653 mm |
| Reach | 374 mm | 391 mm | 407 mm | 424 mm | 441 mm |
| Top Tube Length | 557 mm | 578 mm | 598 mm | 618 mm | 639 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 382 mm | 448 mm | 486 mm | 532 mm | 583 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1070 mm | 1091 mm | 1105 mm | 1125 mm | 1146 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 697 mm | 754 mm | 788 mm | 828 mm | 868 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE 40-D completes the Merida Bignine model. Merida launched 236 bikes of this model so far. Take a sneak peek at all Merida Bignine bikes models from 2018, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
much heavier than average, BIG.NINE 40-D has a weight of 15.2 kg (33.51 lbs). To sum up, it’s 22.58% heavier than the average weight of Crosscountry bikes.
BIG.NINE 40-D components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the BIG.NINE 40-D bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida BIG.NINE 40-D is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
