Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork Fox Float 32
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE LITE
Suspension Fork
Fox 32 Float 29 CTD remote ready O/C (1.5T)- Evolution 100 taper
Drivetrain
Rear Derailleur
Shimano SLX Shadow+
Front Derailleur
Shimano Deore double
Shift Levers
Shimano SLX ispec
Cassette
Shimano CS-HG50-10 11-36
Crank
Shimano SLX 38-24
Bottom Bracket
attached
Chain
KMC X10 10s
Wheels
Front Hub
Shimano Deore / Shimano Deore-12 cen
Rear Hub
Shimano Deore / Shimano Deore-12 cen
Rims
DT Swiss 466D-29
Tires
Continental X-King 29 2.2 fold
Brakes
Brakes
Shimano M615 180 cen / Shimano M615 160 cen
Brake Levers
attached
Cockpit
Handlebar
MERIDA pro OS 700 Flat
Headset
Big Conoid A-bearing
Seat
Saddle
Selle Italia X1
Seatpost
MERIDA pro H SB0 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.52 mm | 1.45 mm | 1.41 mm | 1.45 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 648 mm | 668 mm | 683 mm | 705 mm | 714 mm |
| Rake | 46 mm | 45 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 88 mm | 84 mm | 84 mm | 84 mm |
| Stack | 606 mm | 620 mm | 622 mm | 632 mm | 651 mm |
| Reach | 393 mm | 409 mm | 428 mm | 447 mm | 449 mm |
| Top Tube Length | 577 mm | 597 mm | 617 mm | 639 mm | 647 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 380 mm | 445 mm | 483 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 95 mm | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1078 mm | 1098 mm | 1113 mm | 1135 mm | 1144 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 689 mm | 762 mm | 795 mm | 835 mm | 878 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Big.Nine 800 completes the Merida Bignine model. Merida released 236 bikes variations of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Big.Nine 800 components
Fork
The Fox Float 32 is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Big.Nine 800 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Big.Nine 800 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
