Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Reba
-
Groupset X0, SRAM -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Big.Nine Carbon Comp
Suspension Fork
Rock Shox Reba RL 29 QR SA 100 taper Pushlock - MMX
Drivetrain
Rear Derailleur
SRAM XO long T2
Front Derailleur
SRAM XO HD double
Shift Levers
SRAM XO Trigger
Cassette
SRAM PG1030 11-36
Crank
SRAM S2210 Carbon 38-24 GXP
Bottom Bracket
attached
Chain
KMC X10 10s
Wheels
Front Hub
SRAM M506 Disc
Rear Hub
SRAM M506 Disc
Rims
Mavic EN321-29
Spokes
black stainless
Tires
Schwalbe Racing Ralph 29 Perf. 2.25 fold
Brakes
Brakes
Avid Elixir 5 MM 180 mm Disc / Avid Elixir 5 MM 160 mm Disc
Brake Levers
attached
Cockpit
Handlebar
MERIDA Pro OS 660 Flat
Headset
Big Conoid A-Bearing
Seat
Saddle
Selle Italia X1
Seatpost
Merida Carbon H SB0 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.59 mm | 1.53 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Stack | 614 mm | 628 mm | 630 mm | 640 mm | 658 mm |
| Reach | 392 mm | 394 mm | 413 mm | 433 mm | 435 mm |
| Top Tube Length | 577 mm | 596 mm | 616 mm | 639 mm | 647 mm |
| Seat Tube Angle | 71.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Seat Tube Length | 380 mm | 444 mm | 483 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 95 mm | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Big.Nine CF XO-Edition is part of the Merida Bignine model. There are 236 bikes that carry this model name. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
considerably lighter than average, Big.Nine CF XO-Edition has a weight of 11.1 kg (24.47 lbs). In other words, this model is 11.71% lighter than the average Crosscountry bike.
Overview of components
Fork
The Big.Nine CF XO-Edition comes factory-installed with the RockShox Reba fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Big.Nine CF XO-Edition bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Big.Nine CF XO-Edition has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
