Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork Manitou Markhor
-
Groupset NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE LITE
Suspension Fork
Manitou Markhor Comp, Air, 100mm suspension travel, Tapered, Remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX Eagle
Front Derailleur
no
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX 1230 Eagle, 11-50 teeth, 12 speed
Crank
SRAM NX Eagle, 32 teeth
Bottom Bracket
SRAM BB DUB press-fit MTB 92
Chain
SRAM NX Eagle
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 32 spoke holes, Centerlock
Rear Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 32 spoke holes, Centerlock
Rims
MERIDA Expert CC, 22.8mm inner width
Spokes
Double Butted Black stainless
Tires
Maxxis Ikon, 29x2.2", fold
Brakes
Brakes
Shimano MT-500
Brake Levers
Shimano MT-500
Cockpit
Stem
Merida Expert CC, 31.8mm diameter, -6° stem angle
Handlebar
MERIDA Expert CC, 720mm width, flat
Grips
Merida Comp EC
Headset
MERIDA M2331, 2191025563
Seat
Saddle
MERIDA Comp CC
Seatpost
MERIDA Comp CC, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.43 mm | 1.41 mm | 1.41 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 655 mm | 675 mm | 696 mm | 717 mm | 738 mm |
| Rake | 46 mm | 45 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 88 mm | 87 mm | 87 mm | 87 mm |
| Stack | 613 mm | 618 mm | 627 mm | 641 mm | 660 mm |
| Reach | 402 mm | 421 mm | 438 mm | 454 mm | 468 mm |
| Top Tube Length | 584 mm | 604 mm | 624 mm | 644 mm | 664 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 382 mm | 444 mm | 483 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1079 mm | 1099 mm | 1120 mm | 1141 mm | 1162 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 687 mm | 739 mm | 770 mm | 815 mm | 858 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
BIG.NINE NX-EDITION is part of the Merida Bignine model. 236 bikes variations carry this model name so far. You can easily view all of the Merida Bignine bikes models from 2019, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 11.95 kg (26.35 lbs), the BIG.NINE NX-EDITION model is slightly lighter than average. To sum up, it’s 3.77% lighter than the average weight of Crosscountry bikes.
BIG.NINE NX-EDITION components
Fork
The fork installed on this bike is the Manitou Markhor model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The BIG.NINE NX-EDITION 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida BIG.NINE NX-EDITION has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
