Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Groupset GX, SRAM -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE LITE
Suspension Fork
FS RBA RL 29 15 SA100 oneloc
Drivetrain
Rear Derailleur
SRAM GX 1 A1
Shift Levers
SRAM GX 11
Cassette
SRAM XG-1150-A1 10-42
Crank
SRAM GX1000 30T boost
Chain
KMC X11-1
Wheels
Front Hub
FoBearing disc 15 / FoBearing disc boost XD
Rear Hub
FoBearing disc 15 / FoBearing disc boost XD
Rims
MERIDA Expert CC
Spokes
Double Butted Black stainless
Tires
Maxxis Ikon 29er 2.2 fold
Brakes
Brakes
SRAM Level T Centerline 180 PM / SRAM Level T Centerline 160 PM Stealth-a-majig
Brake Levers
SRAM Level T
Cockpit
Handlebar
MERIDA Expert OS 720 flat
Headset
Big Conoid A-bearing
Seat
Saddle
Prologo Kappa 3
Seatpost
MERIDA Expert SB0 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" | 23" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.43 mm | 1.41 mm | 1.41 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 655 mm | 675 mm | 696 mm | 717 mm | 738 mm |
| Rake | 46 mm | 45 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 88 mm | 87 mm | 87 mm | 87 mm |
| Stack | 613 mm | 618 mm | 627 mm | 641 mm | 660 mm |
| Reach | 402 mm | 421 mm | 438 mm | 454 mm | 468 mm |
| Top Tube Length | 584 mm | 604 mm | 624 mm | 644 mm | 664 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 382 mm | 444 mm | 483 mm | 532 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1079 mm | 1099 mm | 1120 mm | 1141 mm | 1162 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 687 mm | 739 mm | 770 mm | 815 mm | 858 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
BIG.NINE TEAM ISSUE belongs to the Merida Bignine model. 236 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 11.34 kg (25 lbs), the BIG.NINE TEAM ISSUE model is a bit lighter than average. To sum up, it’s 9.35% lighter than the average weight of Crosscountry bikes.
BIG.NINE TEAM ISSUE components
Wheels
The BIG.NINE TEAM ISSUE 2017 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida BIG.NINE TEAM ISSUE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
