Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour XCM HLO -
Groupset Alivio, Sora -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.SEVEN TFS
Suspension Fork
SR 27 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M3000
Shift Levers
Shimano Altus rapidfire
Cassette
Shimano CS-HG200-9 11-34
Crank
SR XCM 40-30-22 CG
Chain
KMC M99
Wheels
Front Hub
Shimano Centerlock
Rear Hub
Shimano Centerlock
Rims
MERIDA Big 7 comp CC
Spokes
Black stainless
Tires
Maxxis Ikon 27.5 2.2 fold
Brakes
Brakes
Shimano M315 180 cen / Shimano M315 160 cen
Brake Levers
attached
Cockpit
Handlebar
MERIDA comp OS 700 R12
Headset
BC OV Neck
Seat
Saddle
MERIDA Sport
Seatpost
MERIDA comp SB12 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 20" | 21.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.51 mm | 1.48 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 619 mm | 629 mm | 639 mm | 659 mm | 658 mm |
| Rake | 42 mm | 42 mm | 43 mm | 41 mm | 42 mm |
| Trail | 81 mm | 81 mm | 77 mm | 79 mm | 75 mm |
| Stack | 576 mm | 581 mm | 588 mm | 607 mm | 618 mm |
| Reach | 377 mm | 385 mm | 397 mm | 412 mm | 412 mm |
| Top Tube Length | 549 mm | 559 mm | 579 mm | 599 mm | 609 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 508 mm | 546 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 125 mm | 135 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1039 mm | 1049 mm | 1059 mm | 1079 mm | 1078 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 657 mm | 692 mm | 735 mm | 798 mm | 827 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
BIG.SEVEN 100 completes the Merida Bigseven model. There are 161 bikes that carry this model name. You can easily view all of the Merida Bigseven bikes models from 2017, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
BIG.SEVEN 100 weighs 13.73 kg (30.27 lbs) and is considerably heavier than the average. In conclusion, the average Crosscountry bike weighs 10.73% less than BIG.SEVEN 100.
Overview of components
Fork
This bike has the SunTour XCM HLO fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the BIG.SEVEN 100 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida BIG.SEVEN 100 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
