Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.SEVEN CF2
Suspension Fork
Rock Shox 30Gold TK27 100 taper poploc
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore direct
Shift Levers
Shimano Deore-i
Cassette
Shimano CS-HG50-10 11-36
Crank
Shimano M612 40-30-22
Bottom Bracket
attached
Chain
KMC X10 10s
Wheels
Front Hub
Formula Centerlock / Formula Centerlock-12
Rear Hub
Formula Centerlock / Formula Centerlock-12
Rims
MERIDA Big 7 Pro D
Tires
MERIDA RACE lite 27 2.1 fold
Brakes
Brakes
Shimano M506 180 cen / Shimano M506 160 cen J
Brake Levers
attached
Cockpit
Handlebar
MERIDA pro OS 700 R12
Headset
Big Conoid A-bearing neck
Seat
Saddle
MERIDA Sport 1
Seatpost
MERIDA pro H SB0 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18.5" | 20" | 21.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.48 mm | 1.48 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 632 mm | 640 mm | 652 mm | 662 mm | 660 mm |
| Rake | 44 mm | 43 mm | 45 mm | 45 mm | 44 mm |
| Trail | 79 mm | 77 mm | 75 mm | 75 mm | 73 mm |
| Stack | 586 mm | 595 mm | 604 mm | 612 mm | 624 mm |
| Reach | 389 mm | 401 mm | 408 mm | 415 mm | 416 mm |
| Top Tube Length | 563 mm | 583 mm | 593 mm | 603 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 508 mm | 546 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 100 mm | 107 mm | 117 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1051 mm | 1059 mm | 1071 mm | 1081 mm | 1079 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 736 mm | 779 mm | 806 mm | 848 mm | 878 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Big.Seven 1000 is part of the Merida Bigseven model. Merida launched 161 bikes of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Big.Seven 1000 components
Wheels
When it comes to wheels, the Big.Seven 1000 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Big.Seven 1000 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
