Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset X5, SRAM -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.SEVEN SPEED
Suspension Fork
Suntour SR 27 XCM HLO 100
Drivetrain
Rear Derailleur
SRAM X5-10
Front Derailleur
SRAM X5
Shift Levers
SRAM Trigger 3 / SRAM Trigger 10
Cassette
Sunrace CSR-10 11-32
Crank
FSA Alfa Drive 44-32-22 (BSA)
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X10
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA Big 7 D
Spokes
stainless silver
Tires
MERIDA 27 2.1
Brakes
Brakes
Tektro Auriga hydraulic 160
Cockpit
Handlebar
MERIDA comp OS 680 R15
Headset
FSA No.10
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 18.5" | 20" | 21.5" | 23" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.57 mm | 1.57 mm | 1.57 mm | 1.57 mm | 1.6 mm | 1.59 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 618 mm | 629 mm | 633 mm | 643 mm | 653 mm | 652 mm | 662 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 43 mm | 43 mm |
| Trail | 85 mm | 85 mm | 81 mm | 81 mm | 81 mm | 77 mm | 77 mm |
| Stack | 587 mm | 592 mm | 603 mm | 613 mm | 622 mm | 634 mm | 643 mm |
| Reach | 368 mm | 377 mm | 383 mm | 390 mm | 397 mm | 397 mm | 404 mm |
| Top Tube Length | 544 mm | 554 mm | 569 mm | 579 mm | 589 mm | 599 mm | 609 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm | 508 mm | 546 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm | 135 mm | 145 mm | 155 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1036 mm | 1047 mm | 1051 mm | 1062 mm | 1072 mm | 1071 mm | 1081 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 641 mm | 677 mm | 722 mm | 755 mm | 787 mm | 817 mm | 847 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
BIG.SEVEN 70 belongs to the Merida Bigseven model. Merida launched 161 bikes of this model so far. Take a sneak peek at all Merida Bigseven bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 14 kg (30.86 lbs), Merida bike is considerably heavier than average. In conclusion, the average Crosscountry bike weighs 12.9% less than BIG.SEVEN 70.
Overview of components
Fork
The BIG.SEVEN 70 comes factory-installed with the SunTour XCM HLO fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Merida BIG.SEVEN 70 2016, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
