Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Reba
-
Groupset X0, SRAM -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Big.Seven Carbon Comp R12
Suspension Fork
Rock Shox Reba RL 27 QR SA 100 taper Pushlock - MMX
Drivetrain
Rear Derailleur
SRAM XO long T2
Front Derailleur
SRAM XO HD double
Shift Levers
SRAM XO Trigger
Cassette
SRAM PG1030 11-36
Crank
SRAM S2210 Carbon 38-24 GXP
Bottom Bracket
attached
Chain
KMC X10 10s
Wheels
Front Hub
SRAM M506 Disc / SRAM M746 Disc R12
Rear Hub
SRAM M506 Disc / SRAM M746 Disc R12
Rims
Mavic EN321-27
Spokes
black stainless
Tires
Schwalbe Racing Ralph 27 Perf. 2.1 fold
Brakes
Brakes
Avid Elixir 7 MM 180 mm Disc / Avid Elixir 7 MM 160 mm Disc w/CJ
Brake Levers
attached
Cockpit
Handlebar
MERIDA Pro OS 660 R12
Headset
Big Conoid A-Bearing Neck
Seat
Saddle
ProLogo Kappa Evo
Seatpost
Merida Carbon H SB0 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18.5" | 20" | 21.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.48 mm | 1.48 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Stack | 586 mm | 595 mm | 604 mm | 612 mm | 624 mm |
| Reach | 389 mm | 401 mm | 408 mm | 415 mm | 416 mm |
| Top Tube Length | 563 mm | 583 mm | 593 mm | 603 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 508 mm | 546 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 100 mm | 107 mm | 117 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Big.Seven CF XO-Edition is part of the Merida Bigseven model. 161 bikes variations carry this model name so far. Take a sneak peek at all Merida Bigseven bikes models from 2014, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Merida Big.Seven CF XO-Edition it’s weighing 10.6 kg (23.37 lbs). At this weight, is much lighter than average. To sum up, it’s 16.98% lighter than the average weight of Crosscountry bikes.
Big.Seven CF XO-Edition components
Fork
Merida Big.Seven CF XO-Edition 2014 bike is equipped with the RockShox Reba fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Merida Big.Seven CF XO-Edition 2014, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
