Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset CUES, Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.TRAIL TFS, material: aluminium, 29x2.5" max. wheelsize, 148x12 mm axle standard, BSA bottom bracket standard
Suspension Fork
Rock Shox Recon Silver RL, 140 mm suspension travel, Tapered, 42 mm fork offset
Drivetrain
Rear Derailleur
Shimano CUES U6000, GS
Shift Levers
Shimano SL-MT500-L
Cassette
Shimano LG300, 11-48 teeth, 10 speed
Crank
Shimano CUES U6000, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano LG500
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TC500-B, 110x15 mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TC500-HM-B, 148x12 mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TR, 29 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
Maxxis Dissector, 29x2.4", fold, TR EXO Dual
Brakes
Brakes
Tektro Gemini M530, 4 piston, 2 piston
Cockpit
Handlebar
MERIDA COMP TR, material: aluminium, 780 mm width, 20 mm rise
Headset
MERIDA M4455
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP TR, 30.9 mm diameter, 0 mm setback, S: 125 mm travel seatpost - M/L: 150 mm travel seatpost - XL/XXL 175 mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.533 mm | 1.474 mm | 1.429 mm | 1.387 mm | 1.318 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 723 mm | 745 mm | 769 mm | 793 mm | 818 mm |
| Rake | 41 mm | 41 mm | 41 mm | 41 mm | 41 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 636 mm | 641 mm | 650 | 659 mm | 659 mm |
| Reach | 415 mm | 435 mm | 455 mm | 475 mm | 500 mm |
| Top Tube Length | 579 mm | 600 mm | 622 mm | 645 mm | 670 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 380 mm | 410 mm | 430 mm | 450 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1150 mm | 1172 mm | 1196 mm | 1220 mm | 1245 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 716 mm | 723 mm | 725 mm | 728 mm | 730 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
BIG.TRAIL 500 belongs to the Merida Bigtrail model. 25 bikes variations carry this model name so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Merida BIG.TRAIL 200 2024 is the most affordable bike of this model and has a price of 898$. On the other hand, Merida BIG.TRAIL 700 2024, is the most expensive and costs 2182$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2024 for 1284$. In conclusion, this bike price is 115.11% smaller than the price of the average Trail bike.
BIG.TRAIL 500 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Merida BIG.TRAIL 500 2024, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida BIG.TRAIL 500 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
Merida BIG.TRAIL 500 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
