Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 130mm -
Fork RST
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.TRAIL
Suspension Fork
RST F1RST 27.5+ 130 boost
Drivetrain
Rear Derailleur
SRAM NX 11
Shift Levers
SRAM NX 11
Cassette
SRAM PG-1130 11-42
Crank
SRAM NX XSYNC 28 STEEL
Chain
KMC X11-1
Wheels
Front Hub
FoBearing disc 15 boost / FoBearing disc boost
Rear Hub
FoBearing disc 15 boost / FoBearing disc boost
Rims
MERIDA Expert TP
Spokes
Black stainless
Tires
Maxxis Rekon 27.5+ 2.8 fold
Brakes
Brakes
Tektro Gimini hydraulic 180
Brake Levers
Tektro Gimini
Cockpit
Handlebar
MERIDA EXPERT 35 760
Headset
Big Conoid S-bearing neck
Seat
Saddle
MERIDA Sport
Seatpost
MERIDA EXPERT Dropper 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.51 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 702 mm | 725 mm | 749 mm | 773 mm |
| Rake | 51 mm | 50 mm | 51 mm | 51 mm |
| Trail | 92 mm | 93 mm | 92 mm | 92 mm |
| Stack | 644 mm | 654 mm | 663 mm | 672 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 601 mm | 623 mm | 646 mm | 669 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1130 mm | 1153 mm | 1177 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 669 mm | 706 mm | 739 mm | 770 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
BIG.TRAIL 600 completes the Merida Bigtrail model. 20 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit heavier than average, BIG.TRAIL 600 has a weight of 13.85 kg (30.53 lbs). To sum up, it’s 6.7% heavier than the average weight of Trail bikes.
Overview of components
Fork
Merida BIG.TRAIL 600 2017 bike is equipped with the RST fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on BIG.TRAIL 600 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
The Merida model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
