Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Revelation RC
-
Groupset SLX, XT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.TRAIL
Suspension Fork
Rock Shox Revelation RC air fork with tapered steered, 130mm travel and 15mm bolt through axle, Boost
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX Shadow
Front Derailleur
N/A
Shift Levers
Shimano XT rapid fire shifter, 11 speed
Cassette
Shimano M7000, 11 speed, 11-46 teeth
Crank
Shimano SLX 30 teeth with MRP 1X TR upper chainguard
Chain
KMC X11-1
Chain Guide
MRP 1x TR upper
Pedals
None included
Wheels
Front Hub
Boost standard, Sealed bearing 15mm front and Shimano Deore 12mm rear bolt through axles, centerlock
Rear Hub
Boost standard, Sealed bearing 15mm front and Shimano Deore 12mm rear bolt through axles, centerlock
Rims
MERIDA Expert TP with 35mm inner width - tubeless ready
Spokes
Double Butted Black stainless
Tires
Maxxis Rekon 27.5+ x 2.8" folding
Brakes
Brakes
Shimano M500 hydraulic disc, 180mm rotors
Brake Levers
Shimano M500
Cockpit
Stem
Merida Expert TR, 3d forged 6061 aluminium, 35mm long, oversize clamp
Handlebar
MERIDA Expert TR 35mm rise 780mm wide
Headset
MERIDA M2333
Seat
Saddle
MERIDA Sport
Seatpost
MERIDA Expert Dropper 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.51 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 702 mm | 725 mm | 749 mm | 773 mm |
| Rake | 51 mm | 50 mm | 51 mm | 51 mm |
| Trail | 92 mm | 93 mm | 92 mm | 92 mm |
| Stack | 644 mm | 654 mm | 663 mm | 672 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 601 mm | 623 mm | 646 mm | 669 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1130 mm | 1153 mm | 1177 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 669 mm | 706 mm | 739 mm | 770 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
BIG.TRAIL 700 is part of the Merida Bigtrail model. 20 bikes variations carry this model name so far. Take a sneak peek at all Merida Bigtrail bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 13.35 kg (29.43 lbs), Merida bike is slightly heavier than average. In short, the average Trail bike weight is 2.85% lower than this one.
Overview of components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the BIG.TRAIL 700 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BIG.TRAIL 700 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
