Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset SLX, XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.TRAIL TFS, material: aluminium, 29x2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard, SRAM-UDH Hanger
Suspension Fork
FOX 34 Float Performance, Air, 140mm suspension travel, Tapered, 44mm fork offset, 29x2.6" max. wheelsize
Drivetrain
Rear Derailleur
Shimano SLX M7100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-IL / Shimano XT, Multi Release
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Race Face Aeffect, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
Race Face BSA 68/73 – 24mm
Chain
KMC X12
Wheels
Front Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Tires
Front: Maxxis Dissector, 29x2.4", fold, TR EXO Dual, Rear: Maxxis Dissector, 29x2.4", fold, TR EXO Dual
Brakes
Brakes
Shimano SLX M7120, 4 piston
Cockpit
Stem
MERIDA EXPERT TR, material: aluminium, 35mm diameter, 0° stem angle, 50 mm
Handlebar
MERIDA EXPERT TR, material: aluminium, 780mm width, 20mm rise
Headset
MERIDA M2331
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M/L: 150mm travel seatpost - XL/XXL 175mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.48 mm | 1.43 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 723 mm | 745 mm | 769 mm | 793 mm | 818 mm |
| Rake | 41 mm | 41 mm | 41 mm | 41 mm | 41 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 633 mm | 638 mm | 647 mm | 656 mm | 656 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm | 497 mm |
| Top Tube Length | 576 mm | 597 mm | 619 mm | 642 mm | 667 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 380 mm | 410 mm | 430 mm | 450 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1147 mm | 1169 mm | 1193 mm | 1217 mm | 1242 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 713 mm | 720 mm | 722 mm | 725 mm | 727 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
BIG TRAIL 700 is part of the Merida Big Trail model. There are 4 bikes that carry this model name. You can easily view all of the Merida Big Trail bikes models from 2023, here.
Model range prices
Merida BIG TRAIL 400 2023 is the most economical model, with a starting price of 1460$. Merida BIG TRAIL 700 2023 on the other hand costs 2676$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Merida BIG TRAIL 700 price was 2676$. Comparing the average cost of a Trail bike to this one, you will see that BIG TRAIL 700 price is 3.21% smaller.
Overview of components
Fork
Merida BIG TRAIL 700 2023 bike is equipped with the Fox Performance Float 34 fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on BIG TRAIL 700 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BIG TRAIL 700 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the BIG TRAIL 700. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
