Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Fork RockShox Pike RC -
Groupset X01, X1 -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.TRAIL
Suspension Fork
FS PIKE RC 27.5"+ 130 BOOST TC
Drivetrain
Rear Derailleur
SRAM XO1 11s
Shift Levers
SRAM X1 11
Cassette
SRAM XG-1175 10-42
Crank
SRAM DESCENDANT
Chain
KMC X11-1
Wheels
Front Hub
attached
Rear Hub
attached
Rims
XM 1501 SPLINE ONE 40 Boost TC
Spokes
attached
Tires
Maxxis Rekon 27.5+ 2.8 fold
Brakes
Brakes
SRAM Guide R 180 PM
Brake Levers
SRAMe Guide R
Cockpit
Handlebar
MERIDA EXPERT 35 760
Headset
Big Conoid A-bearing neck
Seat
Saddle
Prologo Nago Evo X15
Seatpost
Rock Shox Reverb Stealth 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.51 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 702 mm | 725 mm | 749 mm | 773 mm |
| Rake | 51 mm | 50 mm | 51 mm | 51 mm |
| Trail | 92 mm | 93 mm | 92 mm | 92 mm |
| Stack | 644 mm | 654 mm | 663 mm | 672 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 601 mm | 623 mm | 646 mm | 669 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1130 mm | 1153 mm | 1177 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 669 mm | 706 mm | 739 mm | 770 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
BIG.TRAIL 900 completes the Merida Bigtrail model. Merida launched 20 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Merida BIG.TRAIL 900 it’s weighing 12.78 kg (28.18 lbs). At this weight, is slightly heavier than average. In other words, this model is 3.06% heavier than the average Crosscountry bike.
BIG.TRAIL 900 components
Fork
The RockShox Pike RC is included from the factory. It has a travel distance of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the BIG.TRAIL 900 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BIG.TRAIL 900 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
