Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard, MUK 5 Hanger
Suspension Fork
Suntour NEX HLO, Coil, 63mm suspension travel, Lockout, 700x48C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M370
Shift Levers
Shimano Altus
Cassette
Shimano HG200, 11-34 teeth, 9 speed
Crank
SAMOX, AF29-321SSS-P, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
FSA TH-7420ST Cartridge Bearing
Chain
KMC M99
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild
Brakes
Brakes
Tektro M275, 2 piston
Brake Levers
Tektro M275
Disk Rotors
Shimano RT10, 160 mm
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 31.8mm diameter, adjustable, 80 mm-XXS/XS/S, 90 mm-M/L, 100 mm-XL
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2346 Neck
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA TK, 30.9mm diameter, 10mm setback, 40mm seatpost suspension travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.61 mm | 1.64 mm |
| Front Center | 634 mm | 645 mm | 653 mm |
| Rake | 42 mm | 42 mm | 41 mm |
| Trail | 76 mm | 76 mm | 74 mm |
| Stack | 633 mm | 647 mm | 669 mm |
| Reach | 395 mm | 401 mm | 408 mm |
| Top Tube Length | 582 mm | 592 mm | 612 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1087 mm | 1098 mm | 1106 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 750 mm | 784 mm | 819 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
CROSSWAY 100 completes the Merida Crossway model. Merida launched 210 bikes of this model so far. You can easily view all of the Merida Crossway bikes models from 2022, here.
Model range prices
Merida CROSSWAY 20-D (L) 2022 is the cheapest bike model and costs 560$. Merida CROSSWAY 300 2022 is the most expensive one and costs 1077$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Merida CROSSWAY 100 price was 955$. In conclusion, this bike price is 69.93% more expensive than the price of the average Hybrid bike.
CROSSWAY 100 components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Merida CROSSWAY 100 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CROSSWAY 100 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
CROSSWAY 100 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
