Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour NEX HLO, Coil, 63mm suspension travel, Lockout, 700x48C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Alivio T4000, SGS
Front Derailleur
Shimano M370
Shift Levers
Shimano Altus
Cassette
Shimano HG200, 11-34 teeth, 9 speed
Crank
Samox AF29-321SSS-P, 48-35-26 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
FSA TH-7420ST Cartridge Bearing
Chain
KMC M99
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild, Rear: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild
Brakes
Brakes
Tektro M275, 2 piston
Brake Levers
Tektro M275
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 31.8mm diameter, adjustable, XXS/XS/S/M 95 mm, L/XL 110 mm
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2346
Seat
Saddle
MERIDA CROSS SPORT
Seatpost
MERIDA TK, 30.9mm diameter, 10mm setback, 45mm seatpost suspension travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.61 mm | 1.64 mm |
| Front Center | 634 mm | 645 mm | 653 mm |
| Rake | 42 mm | 42 mm | 41 mm |
| Trail | 76 mm | 76 mm | 74 mm |
| Stack | 633 mm | 647 mm | 669 mm |
| Reach | 395 mm | 401 mm | 408 mm |
| Top Tube Length | 582 mm | 592 mm | 612 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1087 mm | 1098 mm | 1106 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 750 mm | 784 mm | 819 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
CROSSWAY 100 belongs to the Merida Crossway model. 210 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida CROSSWAY 20-D (L) 2023 is the cheapest bike model and costs 560$. Merida CROSSWAY 300 2023 is the most expensive one and costs 1077$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Merida CROSSWAY 100 price was 955$. In conclusion, this bike price is 69.93% more expensive than the price of the average Hybrid bike.
Overview of components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on CROSSWAY 100 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida CROSSWAY 100 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
CROSSWAY 100 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
