Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS LADY
Suspension Fork
Suntour NEX 63mm fork with lockout
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M370
Shift Levers
Shimano Altus 27 speed rapid fire shifters
Cassette
Shimano CS-HG200, 9 speed, 11-34 teeth
Crank
Suntour XCR 48-36-26 with chainguard
Chain
KMC M99
Wheels
Front Hub
Shimano Centerlock quick release hubs
Rear Hub
Shimano Centerlock quick release hubs
Rims
MERIDA Comp D
Spokes
Black stainless
Tires
MERIDA Speed 40c with reflective strip
Brakes
Brakes
Shimano M315 hydraulic disc, 160mm rotors
Brake Levers
Shimano M315
Cockpit
Handlebar
MERIDA Comp 660mm wide 25mm rise
Headset
MERIDA M2346
Seat
Saddle
Crossway Sport
Seatpost
HL SP-405 Suspension 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.56 mm | 1.56 mm | 1.57 mm | 1.6 mm |
| Front Center | 629 mm | 634 mm | 638 mm | 649 mm | 658 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 75 mm | 75 mm | 72 mm | 72 mm | 68 mm |
| Stack | 618 mm | 618 mm | 629 mm | 644 mm | 665 mm |
| Reach | 392 mm | 397 mm | 403 mm | 409 mm | 416 mm |
| Top Tube Length | 567 mm | 572 mm | 587 mm | 597 mm | 617 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1087 mm | 1092 mm | 1096 mm | 1107 mm | 1116 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 657 mm | 657 mm | 657 mm | 658 mm | 658 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
CROSSWAY 100 LADY completes the Merida Crossway model. Merida released 210 bikes variations of this model so far. You can easily view all of the Merida Crossway bikes models from 2018, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Hybrid bikes average weight
On a deeper look, we notice that the average weight of a Hybrid bike is 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
CROSSWAY 100 LADY weighs 13.52 kg (29.81 lbs) and is slightly lighter than the average. In other words, this model is 2.44% lighter than the average Hybrid bike.
CROSSWAY 100 LADY components
Fork
This bike has the SunTour NEX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the CROSSWAY 100 LADY model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida CROSSWAY 100 LADY is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
